Ruijie RSR10 Series Hardware Installation Manual page 62

Chapter 1 Product Overview
Attribute
Frequency range
VSWR
Input impedance
Gain
Polarization
Interface type
Length
Color
Operating temperature
Cable length
1.3.12.4 Installing the SIM Card
Step 1 Open the SIM slot according to the indicated OPEN direction.
Step 2 Insert the SIM card into the slot.
Step 3 Close the slot in the opposite direction of OPEN.
Figure: SIM slot
1-52
Parameter
824-960 MHz/1710-2170 MHz
≤ 2.5
50 ohms
≥ 3dBi
Vertical
SMA-J
224mm
Black
-40℃ to 60℃
3m
Installation Manual
