Ruijie RSR10/RSR20 Series Routers
Hardware Installation Manual (V2.00)

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the RSR10 Series and is the answer not in the manual?

Questions and answers

Related Manuals for Ruijie RSR10 Series

Summary of Contents for Ruijie RSR10 Series

  • Page 1 Ruijie RSR10/RSR20 Series Routers Hardware Installation Manual (V2.00)
  • Page 2 Ruijie Networks Ltd. ©2000-2012 All rights reserved. Title to this manual shall solely remain with Ruijie Networks Ltd. Without our written permission, this document may not be excerpted, reproduced, transmitted, or otherwise in all or in part by any party in any means.
  • Page 3 Preface Thank you for buying Ruijie series of routers. This manual details the steps that you need to follow to install them. Version Description This manual applies to Ruijie RSR10/RSR20 series routers. Contents This manual provides the hardware features, installation setting, maintenance, and fixing of common problems of Ruijie RSR10/RSR20 series routers.

  • Page 4: Related Documents

    Information Feedback  If you read the product documentation of Ruijie Networks on the Internet, you can send any of your comments on our documentation on line.  You can also send any of your comments on our documentation via E-Mail at: service@ruijie.com.cn...

  • Page 5: Obtaining Technical Assistance

    Obtaining Technical Assistance Ruijie Networks provides excellent technical support services for all our products. You can obtain the technical assistance you need through any of the following channels:  Ruijie Networks Website From which you can obtain the latest product documentation, causes and problems analysis of product faults, application solutions, and software upgrade.
  • Page 6 Warning, danger or alert in the operation. Warning Precaution, attention or reminder in the operation. Caution Note, prompt, tip or any other necessary supplement or explanation for the operation. Note...

  • Page 7: Table Of Contents

    Contents Product Overview..........................1-1 RSR10 Series Routers.......................1-1 1.1.1 RSR10-02........................1-1 RSR20 Series Routers.......................1-5 1.2.1 RSR20-04 Series Routers.....................1-5 1.2.2 RSR20-14 Series Routers.....................1-8 1.2.3 RSR20-18 Series Routers..................1-13 1.2.4 RSR20-24 Series Routers..................1-18 SIC Card Introduction ......................1-23 1.3.1 SIC-1HS Sync Interface Card ..................1-23 1.3.2...
  • Page 8 1.5.7 Easy Upgrade......................1-67 Preparing for Installation ........................2-1 Safety Precautions........................2-1 Installation Environment Requirements ..................2-1 2.2.1 Temperature and Humidity Requirements ..............2-1 2.2.2 Cleanness Requirements....................2-2 2.2.3 Anti-static Requirements ....................2-3 2.2.4 Anti-interference Requirements ..................2-3 2.2.5 Anti-lightning Requirements ..................2-3 2.2.6 Checking the Installation ....................2-4 Installation Tools and Equipment ....................2-4 Installing Router ..........................
  • Page 9 6.1.3 Connecting An E1 Interface ..................6-4 6.1.4 Connecting the Console Interface.................6-5 Order Information........................6-5...

  • Page 11: Product Overview

    Product Overview The RSR10/RSR20 series routers is a data communication product independently developed by Ruijie Networks Co. Ltd. by using advanced semiconductor technologies and communication control technologies Ruijie series routers are developed in full compliance with international standards, therefore, it is similar to major routers in terms of use and configuration approach.

  • Page 12: Rsr10-02

    Chapter 1 Product Overview Installation Manual The SIC line cards are divided into 4 types, as shown in the following table. Supported SIC line card SIC Type SIC-1A, SIC-8A, SIC-1B-U, SIC-1B-S/T, SIC-2FXS, SIC-2FXO Class A SIC-1HS,SIC-3G-TD, SIC-3G-CDMA, SIC-3G-WCDMA Class B SIC-1CE1, SIC-1E1-F Class C SIC-4ESW...
  • Page 13 Certification Passed the test of telecom access network equipment by the MII 1.1.1.3 Indicators and Appearance Figure 1-1 Front panel of Ruijie RSR10-02 router ○ 1 Indicator; ○ 2 Console; ○ 3 Interface Ethernet 0/0; ○ 4 Interface Ethernet 0/1;...
  • Page 14 Chapter 1 Product Overview Installation Manual Figure 1-2 Back panel of Ruijie RSR10-02 router ○ 1 SIC card slot1; ○ 2 SIC card slot2; ○ 3 Power switch; ○ 4 Input power interface; ○ 5 Enclosure ground interface; If you cannot determine the number of the slot where the current module resides, you can execute the show slots command in the privileged EXE mode.

  • Page 15: Rsr20 Series Routers

    Overview The RSR20-04 modular router is an enterprise-oriented network product independently developed by Ruijie Networks. Designed with a modular structure and 32-bit high-performance RISC microprocessor technology, it is based on our independently developed high-performance network operating system platform, which is compatible with the standard configuration GUIs of the mainstream products and delivers easy configuration.
  • Page 16 Chapter 1 Product Overview Installation Manual SIC-4ESW Class D The following table shows the SIC cards supported by the RSR20-04 slots. Class A Class B Class C Class D Slot 1 √ √ Slot 2 √ √ Slot 3 √ √...
  • Page 17 Certification Passed the test of telecom access network equipment by the MII 1.2.1.3 Indicators and Appearance Figure 1-3 Front panel of Ruijie RSR20-04 router ○ 1 Indicator; ○ 2 Console; ○ 3 Backup interface AUX; ○ 4 Interface Ethernet 0/0;...

  • Page 18: Rsr20-14 Series Routers

    < 30W consumption Operating ambient temperature 0~45°C -40~70°C Storage ambient temperature Operating humidity 10~90%RH 1.2.2 RSR20-14 Series Routers 1.2.2.1 Overview The RSR20-14 modular router is an enterprise-oriented network product independently developed by Ruijie Networks. Designed with a modular structure and 32-bit...
  • Page 19 Installation Manual Chapter 1 Product Overview high-performance RISC microprocessor technology, it is based on our independently developed high-performance network operating system platform, which is compatible with the standard configuration GUIs of the mainstream products and delivers easy configuration. The RSR20-14 router provides a great variety of network security features. It delivers a self-contained redundancy backup solution and IP multicast protocols, and provides rich QoS features, offering a three-network-in-one solution for small- and medium-sized enterprises.
  • Page 20 Chapter 1 Product Overview Installation Manual NMX Slots NMX-24ESW √ NMX-24ESW-L2 √ The NMX switch module, SIC-4ESW and the Eth0/1 on the panel cannot be used at the same time. They are prioritized in the following order: NMX switch module > SIC-4ESW > Eth0/1. That is, once the NMX switch module is inserted, the SIC-4ESW and Eth0/1 cannot be used.
  • Page 21 Certification RSR20-14 has passed the test of telecom access network equipment by the MII 1.2.2.3 Indicators and Appearance Figure 1-5 Front panel of Ruijie RSR20-14 router ○ 1 Status indicator; ○ 2 Console; ○ 3 Backup interface AUX; ○ 4 Interface Ethernet 0/0;...
  • Page 22 The router version information includes the slot number of each Note module. 1.2.2.4 Parameters The following table lists the feature parameters of Ruijie RSR20-14 Item RSR20-14 One Console port, one AUX port, two USB interfaces Default Configuration and three 10/100M Ethernet ports 4 (In according with user’s requirement, configure up...

  • Page 23: Rsr20-18 Series Routers

    Overview The RSR20-18 modular router is an enterprise-oriented network product independently developed by Ruijie Networks. Designed with a modular structure and 32-bit high-performance RISC microprocessor technology, it is based on our independently developed high-performance network operating system platform, which is compatible with the standard configuration GUIs of the mainstream products and delivers easy configuration.
  • Page 24 Chapter 1 Product Overview Installation Manual Connects asyn interface terminals, entwork terminals and PCs at the same time   Addresses the security requirements in the finance industry  Serves as the access router of large- and medius-sized branches The RSR20-18 can be configured with up to eight SIC cards and one NMX switch module. For the easy to use, each slot is marked with the supported card type.
  • Page 25 Installation Manual Chapter 1 Product Overview The NMX switch module, SIC-4ESW and the Eth0/1 on the panel cannot be used at the same time. They are prioritized in the following order: NMX switch module > SIC-4ESW > Eth0/1. Note Up to 6 SIC-2FXS and SIC-2FXO line cards can be respectively supported.
  • Page 26 Chapter 1 Product Overview Installation Manual 1.2.3.3 Indicators and Appearance Figure 1-7 Front panel of Ruijie RSR20-18 router ○ 1 Status indicator; ○ 2 Console; ○ 3 Backup interface AUX; ○ 4 Interface Ethernet 0/0; ○ 5 Interface Ethernet 0/1;...
  • Page 27 The router version information includes the slot number of each Note module. 1.2.3.4 Parameters The following table lists the feature parameters of Ruijie RSR20-18 Item RSR20-18 One Console port, one AUX port, two USB interfaces Default Configuration and three 10/100M Ethernet ports...

  • Page 28: Rsr20-24 Series Routers

    Overview The RSR20-24 modular router is an enterprise-oriented network product independently developed by Ruijie Networks. Designed with a modular structure and 32-bit high-performance RISC microprocessor technology, it is based on our independently developed high-performance network operating system platform, which is compatible with the standard configuration GUIs of the mainstream products and delivers easy configuration.
  • Page 29 Installation Manual Chapter 1 Product Overview The SIC line cards are divided into 4 types, as shown in the following table. Supported SIC line card SIC Type SIC-1A, SIC-8A, SIC-1B-U, SIC-1B-S/T, SIC-2FXS, SIC-2FXO, Class A SIC-1HS, SIC-3G-TD, SIC-3G-CDMA, SIC-3G-WCDMA, Class B SIC-1HS-V35 SIC-1CE1, SIC-1E1-F Class C...
  • Page 30 Chapter 1 Product Overview Installation Manual SIC-4ESW can only be inserted in SIC slot 1. V2.X hardware versions NMX-4E1/CE1H NMX-8E1/CE1H must be used combining with the mainprogram of the Note 10.3(4b3) and the higher version. And the mainprogram of 10.3(4b3) version support only the E1mode of this two cards.
  • Page 31 Installation Manual Chapter 1 Product Overview 1.2.4.3 Indicators and Appearance Figure 1-9 Front panel of Ruijie RSR20-24 router ○ 1 Status indicator; ○ 2 Console; ○ 3 Backup interface AUX; ○ 4 Interface Ethernet 0/0; ○ 5 Interface Ethernet 0/1;...
  • Page 32 If you cannot determine the number of the slot where the current module resides, you can execute the show slots command in the privileged EXE mode. The router version information includes the slot number of each Note module. 1.2.4.4 Parameters The following table lists the feature parameters of Ruijie RSR20-24 1-22...

  • Page 33: Sic Card Introduction

    Installation Manual Chapter 1 Product Overview Item RSR20-24 One Console port, one AUX port, two USB interfaces Default Configuration and two 10/100M Ethernet ports 4 (In according with user’s requirement, configure up SIC card slot to four SIC cards) Processor RISC high performance network processor BOOT ROM 512MB...
  • Page 34 Chapter 1 Product Overview Installation Manual Indicator Description Solid on means the physical connection is set up. Link OFF means the physical connection is unsuccessfully On means the sub-card initialization after power on is done. Off means the sub-card initialization after power on is unsuccessful.
  • Page 35 Installation Manual Chapter 1 Product Overview One end of this cable is the DB25 male connector, the other end is the DB26 male connector. V.24DTE cable  V.24 DCE One end of this cable is the DB25 female connector, the other end is the DB26 male connector.

  • Page 36: Sic-1Hs-V35 Sync Interface Card

    Chapter 1 Product Overview Installation Manual V.35DCE cable  V.35 DTE-V.35 DCE Both ends of this cable are DB26 male connectors V.35 DTE-V.35 DCE cable The cables are not provided along with router delivery; users need purchase them separately. All types of cables of SIC-1HS connect to the router through DB26 interface. Pay attention to connectors when purchasing cables.
  • Page 37 Installation Manual Chapter 1 Product Overview Indicator Description On means the sub-card initialization after power on is done. Off means the sub-card initialization after power on is unsuccessful. 1.3.2.2 Module Attributes HS is the abbrevation of the synchronous serial port.The basic features are as follows: SIC-1HS-V35 indexes Protocol V.35...

  • Page 38: Isdn Interface Card

    Chapter 1 Product Overview Installation Manual V.35DTE cable (with DB25 interface) The cables are not provided along with router delivery; users need purchase them separately. The cables of SIC-1HS-V35 connect to the router through DB25 interface. Pay attention to connectors when purchasing cables. For the use of cables, please refer to the chapter 6. 1.3.3 ISDN Interface Card There are two models available:...
  • Page 39 Installation Manual Chapter 1 Product Overview Indicator Description On means the B2 channel is activated. Off means the B2 channel is inactivated. 1.3.3.2 Attributes of the ISDN Interface Card The basic attributes are as below: SIC-1B-U SIC-1B-U Number of ports Interface type RJ45 port (compatible with RJ11) Cable...

  • Page 40: Sic-1E1- F Interface Card

    Chapter 1 Product Overview Installation Manual 1.3.3.3 Module Cable The cables of the SIC-1B-U module are standard telephone cables. The cables of the SIC-1B-S/T module are standard ISDN S/T cables, or RJ45-RJ45 straight-through cables. No router cables are shipped with the routers and need to be ordered separately. 1.3.4 SIC-1E1- F Interface Card SIC card model: SIC-1E1-F...
  • Page 41 Installation Manual Chapter 1 Product Overview SIC-1E1-F Standard compliance ITU-T G.703 Operating temperature: 0°C ~45°C Operating Temperature: Storage temperature: -40°C ~70°C Humidity Operating humidity: 10%~90% EMI: GB 9254-1998 Class A EMS: GB/T 17618-1998 1.3.4.3 Module Cable The types of cables are provided: ...

  • Page 42: Sic-4Esw Interface Card

    Chapter 1 Product Overview Installation Manual Balanced cable ( with crystal jack ) (Considering the possibility of making this cable by userself, the connection mode and the signal description are attached.) Signal connection table: DB9M RJ45 Signal RX Ring RX Tip TX Tip TX Ring ...
  • Page 43 Installation Manual Chapter 1 Product Overview The SIC-4ESW is the Class D line card, which can be used by the slot marked with “D”. The interface card includes one RDY indicator, and four RJ45 connectors, each with one LINK indicator and one ACT indicator. Panel indicator description: Indicator Description...
  • Page 44 Chapter 1 Product Overview Installation Manual Straight cable: Both ends with RJ45 connector of a cable have the same line order. It is  usually used in the connection between the terminal device (such as PC, routers, etc) and HUB or LAN Switch. ...

  • Page 45: Sic-8A Interface Card

    Installation Manual Chapter 1 Product Overview Line order of the crossover cable The signal of the crossover cable is defined as follows: other One end of Corresponding Corresponding Signal end of the Signal the RJ45 color color RJ45 white-green white-green green green white-orange...
  • Page 46 Chapter 1 Product Overview Installation Manual Indicator Description On means the sub-card initialization after power on is done. Off means the sub-card initialization after power on is unsuccessful. 1.3.6.2 Attributes of the SIC-8A Card The basic attributes are as below: SIC-8A Number of ports Interface type...
  • Page 47 Installation Manual Chapter 1 Product Overview One end is a DB68M interface, the other end is attached with eight RJ45 plugs. Asyn cable (with 1-to-8 crystal connector) (Considering the possibility of making this cable by userself, the connection mode and the signal description are attached.
  • Page 48 Chapter 1 Product Overview Installation Manual One end is a DB68M interface, the other end is attached with eight RJ45 crystal jack sockets. Asyn cable (with 1-to-8 crystal jack) For the definition of the cable pin,please refer to the table in the asyn cable (with 1-to-8 crystal connector) section.

  • Page 49: Sic-1A Interface Card

    Installation Manual Chapter 1 Product Overview RJ45(crystal jack)-DB9( female connector) convert connector. No router cables are shipped with the routers and need to be ordered separately. For the use of cables,refer to the chapter 6. 1.3.7 SIC-1A Interface Card SIC card model: SIC-1A 1.3.7.1 Appearance of the Module and Indicators Figure 1-18 Appearance of 1-port asyn interface card...
  • Page 50 Chapter 1 Product Overview Installation Manual SIC-1A Number of ports Interface type RJ45 connector Cable Rollover cable The asyn serial interface supports 9600 to 115200 bps band Rate rate, including 9600, 19200, 38400, 57600 and 115200 bps. The asyn serial interface supports hardware and software auto Flow control flow control Operating temperature: 0°C ~45°C...

  • Page 51: Sic-2Fxs Interface Card

    Installation Manual Chapter 1 Product Overview 1.3.8 SIC-2FXS Interface Card SIC card model: SIC-2FXS 1.3.8.1 Appearance of the Module and Indicators Figure 1-19 Appearance of SIC-2FXS interface card The SIC-2FXS is the Class A line card, which can be used by the slot marked with “A”. The interface card includes the IN USE indicators for ports and one RDY indicator.

  • Page 52: Sic-2Fxo Interface Card

    Chapter 1 Product Overview Installation Manual No router cables are shipped with the routers and need to be ordered separately. 1.3.9 SIC-2FXO Interface Card SIC card model: SIC-2FXO 1.3.9.1 Appearance of the Module and Indicators Figure 1-20 Appearance of SIC-2FXO interface card The SIC-2FXO is the Class A line card, which can be used by the slot marked with “A”.

  • Page 53: Sic-1Ce1 Interface Card

    Installation Manual Chapter 1 Product Overview 1.3.9.3 Module Cable The SIC-2FXO module uses standard phone wires. No router cables are shipped with the routers and need to be ordered separately. 1.3.10 SIC-1CE1 Interface Card SIC card model: SIC-1CE1 1.3.10.1 Appearance of the Module and Indicators Figure 1-21 Appearance of 1-port channelized E1 card (SIC-1CE1) The SIC-1CE1 is the Class C line card, which can be used by the slot marked with “C”.

  • Page 54: Sic-3G-Td Interface Card

    Chapter 1 Product Overview Installation Manual SIC-1CE1 EMS: GB/T 17618-1998 1.3.10.3 Module Cable Three types of cables are provided:  Balanced cable (crystal connector): one end is the DB9 male connector, and the other end is the RJ45 crystal connector. The characteristic impedance of the cable is 120Ω. ...
  • Page 55 Installation Manual Chapter 1 Product Overview Indicator Description Solid on means the link is through. WWAN Flashing means the data is being transmitted. Solid on means the strong signal. RSSI Flashing means the medium/low signal. Off means the weak signal or no signal. Solid on means the HSDPA service is effective.
  • Page 56 Chapter 1 Product Overview Installation Manual When the module runs normally, the RJ-45 interface does not need to connect a cable. Note 1.3.11.3 Module Cable The SMA interface of the SIC-3G-TD module can connect two types of antennas: pole-shaped antenna and 3m extension magnetic antenna. Pole-shaped antenna ...
  • Page 57 Installation Manual Chapter 1 Product Overview Specifications of 3m extension magnetic antenna (ANT-RJ3G3MA): Attribute Parameter Frequency range 824-960 MHz/1710-2170 MHz VSWR ≤ 2.5 Input impedance 50 ohms Gain ≥ 3dBi Polarization Vertical Interface type SMA-J Length 224mm Color Black Operating temperature -40℃...

  • Page 58: Sic-3G-Cdma Interface Card

    Chapter 1 Product Overview Installation Manual 1.3.11.4 Installing the SIM Card Step 1 Open the SIM slot according to the indicated OPEN direction. Step 2 Insert the SIM card into the slot. Step 3 Close the slot in the opposite direction of OPEN. Figure: SIM slot 1.
  • Page 59 Installation Manual Chapter 1 Product Overview 1.3.12.1 Appearance of the Module and Indicators Figure: Appearance of SIC-3G-CDMA interface card The SIC-3G-CDMA is the Class B line card, which can be used by the slot marked with “B”. Panel indicator description: Indicator Description Solid on means that firmware initialization of the line card is...
  • Page 60 Chapter 1 Product Overview Installation Manual SIC-3G-CDMA SMA RF is used to connect antenna. Interface type RJ45 is for the internal commissioning. SMA RF : N/A Cable RJ45: Serial port cable Supported Rate HSDPA (in theory: 3.1 Mbps downlink and 1.8 Mbps uplink) Operating temperature: 0°C ~45°C Operating Temperature: Storage temperature: -40°C ~70°C...
  • Page 61 Installation Manual Chapter 1 Product Overview Attribute Parameter Input impedance 50 ohms 1.8 dBi (824 MHz-960 MHz) Gain 2.0 dBi (1710 MHz-2170 GHz） Polarization Linear Interface type SMA Straight Plug Reverse Length 145mm Color Black Operating temperature -10℃ to 60℃ Cable length None ...
  • Page 62 Chapter 1 Product Overview Installation Manual Attribute Parameter Frequency range 824-960 MHz/1710-2170 MHz VSWR ≤ 2.5 Input impedance 50 ohms Gain ≥ 3dBi Polarization Vertical Interface type SMA-J Length 224mm Color Black Operating temperature -40℃ to 60℃ Cable length 1.3.12.4 Installing the SIM Card Step 1 Open the SIM slot according to the indicated OPEN direction.

  • Page 63: Sic-3G-Wcdma Interface Card

    Installation Manual Chapter 1 Product Overview 1. The gap of the SIM card should be aligned with that of the SIM slot. In this manner, the SIM card can be installed correctly. 2. The SIM slot should be closed when there is no SIM card in it. Otherwise, Note there are risks of damaging the SIM slot.
  • Page 64 Chapter 1 Product Overview Installation Manual Indicator Description Solid on means the HSDPA service is effective. HSDPA Off means there is no HSDPA service. 1.3.13.2 Attributes of the SIC-3G-WCDMA The basic attributes are as below: SIC-3G-WCDMA SMA RF: 1 Number of ports RJ-45: 1 SMA RF is used to connect antenna.
  • Page 65 Installation Manual Chapter 1 Product Overview Pole-shaped antenna specifications Attribute Parameter Frequency range 824-960 MHz/1710-2170 MHz VSWR ≤ 3 Input impedance 50 ohms 1.8 dBi (824 MHz-960 MHz) Gain 2.0 dBi (1710 MHz-2170 GHz） Polarization Linear Interface type SMA Straight Plug Reverse Length 145mm Color...
  • Page 66 Chapter 1 Product Overview Installation Manual Specifications of 3m extension magnetic antenna (ANT-RJ3G3MA): Attribute Parameter Frequency range 824-960 MHz/1710-2170 MHz VSWR ≤ 2.5 Input impedance 50 ohms Gain ≥ 3dBi Polarization Vertical Interface type SMA-J Length 224mm Color Black Operating temperature -40℃...

  • Page 67: Other Sic Cards

    SIM slot. 1.3.14 Other SIC Cards Ruijie Networks currently provides the following SIC cards: SIC-4ESW, SIC-1HS, , SIC-1E1-F, SIC-1HS-V35, SIC-1B-U, SIC-1B-S/T, SIC-8A, SIC-1A, SIC-2FXS, SIC-2FXO, and SIC-1CE1, SIC-3G-TD, SIC-3G-CDMA and SIC-3G-WCDMA. The descriptions of the subsequent SIC cards will be updated in this document as the cards are launched.

  • Page 68: Nmx-24Esw-L2 Interface Card

    Chapter 1 Product Overview Installation Manual 1.4.1.1 Appearance of the Module and Indicators Figure 1-22 Appearance of NMX-24ESW interface card The interface card includes the status indicator of each RJ45 port-LINK/ACT. . Panel indicator description: Indicator Description Solid on means the link is through, OFF not connected. Link/ACT Flash means the data is transmitting.

  • Page 69: Nmx-2Geh Interface Card

    Installation Manual Chapter 1 Product Overview 1.4.2.1 Appearance of the Module and Indicators Figure 1-23 Appearance of NMX-24ESW-L2 interface card The interface card includes the status indicator of each RJ45 port-LINK/ACT. . Panel indicator description: Indicator Description Solid on means the link is through, OFF not connected. Link/ACT Flash means the data is transmitting.
  • Page 70 Chapter 1 Product Overview Installation Manual 1.4.3.1 Appearance of the Module and Indicators Figure 1-24 Appearance of NMX-2GEH interface card The interface card includes two status indicators for each RJ45 port-LINK/ACT and 1000Mbps. Panel indicator description: Indicator Description Solid on means the link is through, OFF not connected. Link/ACT Flash means the data is transmitting.

  • Page 71: Nmx-4Hsh Interface Card

    Installation Manual Chapter 1 Product Overview Mini-GBIC-ZX50:1-port 1000BASE-ZX mini GBIC convert module(LC interface), 50km Mini-GBIC-ZX80:1-port 1000BASE-ZX mini GBIC convert module(LC interface), 80km The transmission media and its features are shown as follows: Media maximum 1000BASE-SX: wavelength 850nm, transmission distance Maximum transmission distnace of 62.5/125um: 220m Maximum transmission distnace of 50/125um: 500m 1000BASE-LX: wavelength 1310nm, Maximum transmission distnace of 62.5/125um: 550m...
  • Page 72 Chapter 1 Product Overview Installation Manual Panel indicator description: Indicator Description Link Solid on means the link is through, OFF not connected. ON means the card initialization after power on is done. OFF means the card initialization after power on is unsuccessful.

  • Page 73: 8)E1/Ce1H Interface Card

    Installation Manual Chapter 1 Product Overview 1.4.5 NMX-4(8)E1/CE1H Interface Card NMX card model (for RSR20-24): NMX-4E1/CE1H; NMX-8E1/CE1H 1.4.5.1 Appearance of the Module and Indicators Figure 1-26 Appearance of NMX-4E1/CE1H Figure 1-27 Appearance of NMX-8E1/CE1H The interface card includes the status indicator for each CE1 port and the Ready indicator for sub card.
  • Page 74 Chapter 1 Product Overview Installation Manual NMX-4E1/CE1H and NMX-8E1/CE1H Storage temperature: -40°C ~70°C Humidity Operating humidity: 10%~90% EMI: GB 9254-1998 Class A EMS: GB/T 17618-1998 1.4.5.3 Module Cable Two types of cables are provided:  4E1 balanced cable  4E1 non-balanced cable The appearances of the above two cables are shown as blow: ...

  • Page 75: Features Of Rsr10/Rsr20 Series Routers

    Routers For software functions, refer to the supporting software description. Note 1.5.1 Rich Protocol Support Ruijie RSR10/RSR20 series routers are applicable to various network environments   Providing RJ45 interfaces for twisted pairs, supporting Ethernet, ARP, and 802.1Q protocols ...

  • Page 76: Friendly User Interfaces

    Chapter 1 Product Overview Installation Manual It supports upgrade via the asynchronous file transfer protocols of X-MODEM.   It supports NAT, ACL and AAA.  It supports IPSEC, L2TP, and PPTP 1.5.2 Friendly User Interfaces  It provides standard operating interfaces and intuitive configuration procedures with each command offering detailed on-line help.

  • Page 77: Diversified Terminal Functions

    Installation Manual Chapter 1 Product Overview VLAN technology  1.5.6 Diversified Terminal Functions  Both the synchronous and asynchronous ports can connect the terminals.  The terminal ports support the autocommand function, which can automatically execute commands. It supports user-based autocommand, which allows different users to execute different commands.

  • Page 79: Preparing For Installation

    UPS is recommended to avoid power failure as well as power interference. Installation Environment Requirements Ruijie routers are intended for use indoors. For their normal operation and maximum service life, they must be installed at locations that meet the following requirements: ...

  • Page 80: Cleanness Requirements

    In addition, static electricity may easily occur in dry weathers, harming the internal circuitry of the routers. High temperature will speed the aging of insulation materials, lowering routers' reliability and shorten their lives. The temperate and humidity requirements of Ruijie RSR 10/20 series routers are as follows:  Temperature: 0ºC~45ºC ...

  • Page 81: Anti-Static Requirements

    Installation Manual Chapter 2 Preparing for Installation 2.2.3 Anti-static Requirements The circuitry of the routers is designed with electrostatic protection, but excessive static electricity may still damage the circuit boards of the routers. The static electricity of the network connected with the routers comes largely from the following sources: ...

  • Page 82: Checking The Installation

    Make sure sufficient spacing is reserved at the air inlets and outlets of the routers for good heat dissipation of the routers. The Ruijie series routers themselves are provided with a fan that works in the following way: taking in cool air through the heat dissipation holes around the enclosure and discharging the air out of the bottom of the enclosure.
  • Page 83 Installation Manual Chapter 2 Preparing for Installation Related devices include:  HUB or switch  CSU/DSU or other DCE device The configuration terminal can be a terminal or a PC installed with the HyperTerminal   Router modules  Power socket...

  • Page 85: Installing Router

    Installation Manual Chapter 3 Installing Router Installing Router Procedure for Installing Router Please follow the following procedure to install the Ruijie series routers to ensure a smooth installation and avoid any damage to the unit: Start Preparations: Read the second chapter and meet the requirements specified.

  • Page 86: Fastening Router

    Mounting on the Workbench 3.2.1 Mounting in the Cabinet The Ruijie series routers is designed with 19-inch standard cabinet. Use the supplied fixing accessory for installation when needed. RSR10-02 can be mounting on the cabinet using the shipped sunk screw and fixing accessories( the fixing accessories should be purchased separately) , as shown in the following figure.
  • Page 87 Installation Manual Chapter 3 Installing Router RSR20-04,RSR20-14.RSR20-18 can be mounting on the cabinet using the shipped sunk screew and fixing accessories, as shown in the following figure. Hanger: Mounting:...
  • Page 88 Chapter 3 Installing Router Installation Manual RSR20-24 can be mounting on the cabinet using the shipped sunk screw and fixing accessories, as shown in the following figure. Hanger: Mounting:...

  • Page 89: Mounting On The Workbench

    No weight is placed on the top of the router. Installing the Power Cable and Grounding Cable Ruijie RSR 10(20) series routers support this AC power supply. AC: 100–240V; 50/60Hz; 2A Make sure that your power supply meets the requirement.

  • Page 90: Connecting The Console

    If so, it means that the power cable is correctly connected. Step 3 For RSR20-14, RSR20-18 and RSR20-24, check the POWER indicator on the front panel is on. If so, it means that the power cable is correctly connected. Connecting the Console Ruijie series routers supply EIA/TIA-232...

  • Page 91: Removing Line Cards

    Installation Manual Chapter 3 Installing Router Place the router in such a way that its rear panel faces you. Remove the blank Step 2 panel with screwdrivers. Flush the line card interface board and the edge of the opening of the back Step 3 panel of the router base.

  • Page 92: Troubleshooting

    Chapter 3 Installing Router Installation Manual Pay attention to the following when you remove a line card: When you have removed a line card and are not going to install another one, install an empty panel in time to protect it against dust and ensure ventilation.

  • Page 93: Starting And Configuring Router

    Installation Manual Chapter 4 Starting and Configuring Router Starting and Configuring Router Starting Router 4.1.1 Setting Up the Configuration Environment When you use the router for the very first time, you will need to configure the router through a console port as follows: Connect the serial port of a character terminal or PC to the Console port of the network output engine through the standard RS232 cable and the Console.

  • Page 94: Startup Process

    Press Ctrl+C to enter Boot Menu ..Main Program File Name rgos.bin, Load Main Program ... Executing program, launch at: 0x00010000 Ruijie General Operating System Software Release Software (tm), RGOS 10.3(4), Release(53498), Compiled Fri Apr 3 08:45:59 CST 2009 by ngcf31...

  • Page 95: Configuring Router

    Installation Manual Chapter 4 Starting and Configuring Router Copyright (c) 1998-2009 by Ruijie Networks. All Rights Reserved. Decompiling or Reverse Engineering is Not Allowed. 00:00:00:00: %MTD_DRIVER-5-MTD_NAND_FOUND: 1 NAND chips(chip size : 33554432) detected 00:00:00:00: %MTD_DRIVER-5-MTD_NAND_FOUND: 1 nand chip(s) found on the target.

  • Page 97: Troubleshooting

    Installation Manual Chapter 5 Troubleshooting Troubleshooting Troubleshooting Power Faults For RSR10-02 and RSR20-04 series, you can determine whether the power system has any fault by the Status indicator on the front panel. For RSR20-14, RSR20-18 and RSR20-24, however, you can determine whether the power system has any fault by the POWRE indicator on the front panel.
  • Page 98 Chapter 5 Troubleshooting Installation Manual When the console port parameters of your router are modified, this may also lead to no display on the terminal. Note...

  • Page 99: Cable Connection

    Installation Manual Chapter 6 Cable Connection Cable Connection This chapter indroduces the use of various cables and converter adapters. Physical Cable Connection 6.1.1 Connecting An Asyn Interface 6.1.1.1 Connecting An Asyn Interface Module to A Modem As a DCE equipment, the modem has two kinds of serial interfaces: DB9F and DB25F. Connecting the asyn interface to Modem The asyn cable with 1-to-8 crystal connector converts the 68-pin connector of the asyn interface into eight RJ45 connectors, and then connects to the DB25F interface of the...
  • Page 100 Chapter 6 Cable Connection Installation Manual The AUX interface connected through a RJ45 rollover cable is same as the asyn card connected through the asyn cable with 1 to 8 crystal connector, , and be similar to Modem in terms of connection. Note Table 6-2 Connect the AUX interface module to Modem Equipment...

  • Page 101: Connecting A Synchronous Interface

    Installation Manual Chapter 6 Cable Connection 6.1.1.3 Connecting the RCMS Asyn Interface to the CONSOLE Interface The RCMS converter cable converts the 68-pin RCMS asyn interface into eight RJ45 connectors, and then connects to the RJ45 connector of the console port of switch/router. This mode applies to such modules as RCMS-16 and RCMS-8.
  • Page 102 Chapter 6 Cable Connection Installation Manual In the laboratory, there is another special application that implements the back-to-back  connection between our company’s syn cards through the V.35 DTE-V.35 DCE cables Table 6-6 Connect the syn interface of the router working under the V.35 mode. Equipment Mode Cable 1...

  • Page 103: Order Information

    Installation Manual Chapter 6 Cable Connection Through 4E1 balanced cable Table 6-10 Connect E1/CE1 interface to base band modem Equipment Cable 1 Peer non-balanced BNC interface NMX-8E1/CE1H cable Base band Modem NMX-4E1/CE1H 4E1 balanced calbe RJ45 interface 6.1.4 Connecting the Console Interface Generally, the console interface of a switch/rotuer comes with a RJ45 connector to connect RJ45 cables through DB9F or connect to the DB9M serial port of PC through the RJ45-DB9 jack matching rollover cable.
  • Page 104 Chapter 6 Cable Connection Installation Manual converter RJ45(crystal jack)-DB25 8AE34-11-- ADAPTER/RJ45F-DB25F female converter CAB-E1 UNBALANCED/DB9M-2*BNC/75 8AE38-11-- Non-balanced cable OHM/3M CAB-E1 BALANCED/DB9M-RJ45M/120 Balanced cable( crystal 8AE39-11-- OHM/3M connector interface) CAB-E1 BALANCED/DB9M-RJ45F/120 Balanced cable( crystal jack 39165-11-- OHM/3M interface) CAB-E1 UNBALANCED/DB25M-8*BNC/75 8AE86-11-- 4E1 non-balanced cable OHM/3M CAB-E1 BALANCED/DB25M-4*RJ45M/120...
