Chapter 1 Product Overview
Figure 1-2 Back panel of Ruijie RSR10-02 router
○ 1 SIC card slot1;
○ 2 SIC card slot2;
○ 3 Power switch;
○ 4 Input power interface;
○ 5 Enclosure ground interface;
Note
1.1.1.4
Parameters
The following table lists the parameters of RSR10-02:
Item
Default Configuration
SIC card slot
Processor
SDRAM
Boot Rom
Data
NAND FLASH
Dimensions (W×H×D)
Input voltage
Whole-system power consumption
Operating ambient temperature
1-4
If you cannot determine the number of the slot where the current module
resides, you can execute the show slots command in the privileged EXE
mode. The router version information includes the slot number of each
module.
RSR10-02
One Console port, two 10/100M Ethernet ports
2 (User can configure up to two SIC cards in
according to requirement.)
RISC high performance processor
64MB
2MB
32MB
268mm×44mm×185mm (1U)
AC100~240V 50~60Hz
< 20W
0~45°C
