RG-RSR77 Series Router
Hardware Installation and Reference Guide V1.07

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the RG-RSR77 Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Ruijie RG-RSR77 Series

Summary of Contents for Ruijie RG-RSR77 Series

  • Page 1 RG-RSR77 Series Router Hardware Installation and Reference Guide V1.07...

  • Page 2: Copyright Statement

    Ruijie Networks reserves all copyrights of this document. Any reproduction, excerption, backup, modification, transmission, translation or commercial use of this document or any portion of this document, in any form or by any means, without the prior written consent of Ruijie Networks is prohibited. are registered trademarks of Ruijie Networks.

  • Page 3: Obtaining Technical Assistance

    It is intended for the users who have some experience in installing and maintaining network hardware. At the same time, it is assumed that the users are already familiar with the related terms and concepts. Obtaining Technical Assistance Ruijie Networks website: http://www.ruijienetworks.com/ Online customer services: http://webchat.ruijie.com.cn...

  • Page 4: Chapter 1 Product Overview

    Chapter 1 Product Overview The Ruijie RSR77 series router is a data communication product independently developed by Ruijie Networks Co. Ltd. by using advanced semiconductor technologies and communication control technologies. Ruijie RSR77 series router is developed in full compliance with international standards;...
  • Page 5 32-port 1000 Mbps copper module and 16-port 1000 Mbps fiber module While purchasing Ruijie RSR77 series modularized routers, the user can select the corresponding functional modules according to his actual needs. The principles for module selection are given below: RSR77-SIP1 supports FNM functional modules ...

  • Page 6: Product Features

    Please refer to the following sections for details about relevant functional modules. All board cards support hot swap, and the procedures thereof are given in the software manual. Product Features Convergence and processing capacity RSR77 enables high speed forwarding through 1000M Ethernet ports. Therefore, it can serve as the core router of large-sized enterprises and the convergence-layer routers on large-sized industrial network.

  • Page 7: Back Panel

    Note: 1: Fan tray module slot 4: Service module slot 2 2: Master control module slot M2 5: Service module slot 1 3: Master control module slot M1 Back Panel Figure 1-2 Back panel of the RSR7704 router Note: 1: Air filter slot 4: Reserved POE power supply slot 2: Power supply slot 2 5: Power supply module handle...
  • Page 8 Figure 1-3 Front panel of the RSR7708 router Note: 1: Fan tray module slot 5: Master control module slot M1 2: Service module slot 4 6: Service module slot 2 3: Service module slot 3 7: Service module slot 1 4: Master control module slot M2 Figure 1-4 Back panel of the RSR7708 router Note:...
  • Page 9  They are not applicable to the Slot4 of RSR7708 V1.0 host.  They are not applicable to the Slot5, Slot8 of RSR7716 V1.0 host. Product Images of the RSR7716 Router Front Panel Figure 1-5 Front panel of the RSR7716 router Note: 1: Fan tray module slot 7: Master control module slot M1...
  • Page 10 Note: 1: Air filter slot 5: Power supply module handle 2: Power supply slot 4 6: Chassis earthing terminal 3: Power supply slot 3 7: Power supply slot 1 4: Power supply slot 2 8: Reserved POE power supply slot Technical Specifications of RSR77 Series Routers Table 1-1 Technical Specifications of the RSR7704 Router Model...
  • Page 11 10GBASE-LAN/WAN-SFP+ STM-1 POS SFP STM-1 CPOS SFP STM-4 POS SFP STM-4 CPOS SFP STM-16 POS SFP STM-16 CPOS SFP E1/CE1, HS, ATM, Power/Fan Power RG-PA300I:100-240V; 50/60Hz; maximum power: 400W RG-PD650I:-36-72V; maximum power: 650W Power redundancy AC power and DC power both support 1+1 redundancy. POE external power Not supported RSR7704-FAN...
  • Page 12 Main control redundancy Supported Requires double main control modules. Interface Type User interface type 100BASE-T RJ45 10/100/1000BASE-TX RJ45 1000BASE-X-SFP 10GBASE-LAN-XFP 10GBASE-LAN/WAN-SFP+ STM-1 POS SFP STM-1 CPOS SFP STM-4 POS SFP STM-4 CPOS SFP STM-16 POS SFP STM-16 CPOS SFP E1/CE1, HS, ATM, Power/Fan Power RG-PA300I:100-240V;...
  • Page 13 Module slot 2 for main control module Main control module slot Users can set up to 2 main control modules Users can set up to 2 function modules as required on Service module slot each carrier board. Power slot RSR7704 can set up to 4 powers. Hot plugging Supported Cooperates with software version for use.
  • Page 14 without package) Dimensions Dimensions 440mm x 480mm x 495.7mm (L x W x H) Introduction to Chassis of the RSR77 Series Routers Introduction to the RSR7704 Chassis Figure 1-7 Front perspective of the RSR7704 Note: 1: Fan slot 4: Handles at the top of the chassis 2: Fan handle 5: ESD wrist strap jack 3: Chassis handle on the front panel...
  • Page 15 Note: 1: Air filter slot 3: Chassis earthing terminal 2: Power supply module handle 4: Air outlet Introduction to the RSR7708 Chassis Figure 1-9 Front perspective of RSR7708 Note: 1: Fan slot 4: Chassis handle on the front panel 2: Fan handle 5: Handles at the top of the chassis 3:ESD wrist strap jack 6: Air intake...
  • Page 16 Figure 1-10 Back perspective of RSR7708 Note: 1: Air filter slot 3: Chassis handle on the front panel 2: Power supply module handle Air outlet Introduction to the RSR7716 Chassis Figure 1-11 Front perspective of RSR7716 Note: 1: Fan slot 4: Handles at the top of the chassis 2: Fan handle 5: ESD wrist strap jack...
  • Page 17 Note: 1: Air filter slot 3: Chassis earthing terminal 2: Power supply module handle 4: Air outlet The chassis-top handles have a weight limit of 80 kg. Do not use fan handles to move the chassis. Do not use power supply module handles to move the chassis. About Control Modules Sections about RSR7704-SRCMI, RSR7708-SRCMI and RSR7716-SRCMI control modules are applicable to RSR77 series core routers.
  • Page 18 Figure 2-2 Appearance of the RSR7704-SRCMI V1.1X RSR7704-SRCMI module has 13 indicators and one button, and the meanings are shown in table 2-1: Table 2-1 Introduction to the indicators and the button on the front panel of the RSR7704-SRCMI Mark Note Description Off: This control board is a slave control module.

  • Page 19: Image And Indicators

    Mark Note Description Blinking green: reading USB device. Solid green: The device functions normally. Off: USB serial port is not enabled. USB serial port U-Console Solid green: USB serial port is enabled. status indicator It is supported on V1.1X while not on V1.0X. Off: Connection not established.
  • Page 20 Figure 2-3 Appearance of the RSR7708-SRCMI V1.0 Figure 2-4 Appearance of the RSR7708-SRCMI V1.1X RSR7708-SRCMI module has 16 indicators and one button, and the meanings are shown as follows: Table 2-3 Introduction to indicators and the button on the front panel of the RSR7708-SRCMI Mark Note Description...
  • Page 21 Mark Note Description USB0/1 Solid red: The USB device is abnormal. Blinking green: reading USB device. Solid green: The device functions normally. Off: USB serial port is not enabled. USB serial port U-Console Solid green: USB serial port is enabled. status indicator It is supported on V1.1X while not on V1.0X.
  • Page 22 RSR7716-SRCMI Control Module Image and Indicators Figure 2-5 Appearance of the RSR7716-SRCMI V1.0 Figure 2-6 Appearance of the RSR7716-SRCMI V1.1X The RSR7716-SRCMI module has 16 indicators and one button, and the meanings are shown as follows: Table 2-5 Introduction to indicators and the button on the front panel of the RSR7716-SRCMI Mark Note Description...
  • Page 23 Mark Note Description Off: The SD card does not exist, it is not properly inserted, or the line card module is removed; SD card status Solid red: The device is abnormal; indicator Blinking green: reading SD card; Solid green: The device functions normally; Off: The USB device does not exist or has been removed;...

  • Page 24: Func Button

    External interface 1 Console port 1 AUX port 1 MGMT port 2 USB 2.0 interfaces 1 SD interface 1 U-Console port (supported on the board of V1.1 and higher) 1 FUNC button (supported on the board of V1.1 and higher) Maximum power ≤45 W consumption...
  • Page 25 If you only want to reset the system, make sure that no SD card or USB flash disk is inserted or a USB flash disk or an SD card is inserted without software upgrade versions, and then press the FUNC button. Please refer to RG-RSR77 Series Router RGOS 10.4(3b21) Configuration Guide for operation.
  • Page 26 About Carrier Modules The characteristics of the carrier modules supported by Ruijie RSR77 series routers will be introduced respectively. RSR77-SIP1 Carrier Module The RSR77-SIP1 provides no external user interface, and must be used in conjunction with FNM functional modules.
  • Page 27 Image and Indicators Figure 4-2 Appearance of the RSR77-SIP2 The RSR77-SIP2 module has two 1000 M 1000M fiber/copper combo Ethernet interfaces. Each RJ45 interface has one status indicator (Link/ACT), and each SFP optical interface has one Link indicator. Table 4-2 Introduction to indicators on the front panel of the RSR77-SIP2 Mark Note Description...
  • Page 28 Supports two half-height NME modules or one full-height DNME Functional module extension modules Maximum power consumption ≤25 W Interfaces The RSR77-SIP2 provides two 10/100/1000Mbps Ethernet interfaces, and each Gigabit Ethernet interface supports both optical and electrical connectors. The electrical interface adopts the RJ45 connector, while the optical interface adopts the SFP (Small Form-Factor Pluggable) module.
  • Page 29 Cables The module cables and SFP optical parts are sold separately. About Functional Modules The characteristics of the functional modules supported by Ruijie RSR77 series routers will be introduced respectively. 4-port Gigabit Ethernet Fiber/Copper Combo Type I Interface Module (FNM-4GE-1)
  • Page 30 Image and Indicators Figure 5-1 Appearance of the 4-port Gigabit Ethernet module (FNM-4GE-1) Indicators include the port status indicator and line card RDY indicator. Each RJ45 interface has one status indicator (Link/ACT), and each optical interface has one Link indicator. Table 5-1 Introduction to indicators on the front panel of the FNM-4GE-1 Mark Note...
  • Page 31 BOOTROM 2 MB Flash Memory 512 MB DDR2 SDRAM 2 GB Fuse F1: 5A/125V F2: 10A/125V External interface Four 10/100/1000Base-T/1000Base-X multiplexing interfaces Interface standard IEEE 802.3 Lightning protection Vertical 2KV lightning protection Electrostatic safety ESD 6KV contact, 8KV air protection Maximum power ≤25 W consumption...
  • Page 32 Network medium 1000BASE-SX: wavelength 850 nm, and maximum The maximum transmission range of 62.5/125um multi-mode fiber optic cable is transmission 220 m; The maximum transmission range of 50/125um multi-mode fiber optic cable is 500 range 1000BASE-LX: wavelength 1310 nm, The maximum transmission range of 62.5/125um multi-mode fiber optic cable is 550 m;...
  • Page 33 Network medium 1000BASE-SX: wavelength 850 nm, and maximum The maximum transmission range of 62.5/125um multi-mode fiber optic cable is transmission 220 m; The maximum transmission range of 50/125um multi-mode fiber optic cable is 500 range 1000BASE-LX: wavelength 1310 nm, The maximum transmission range of 62.5/125um multi-mode fiber optic cable is 550 m;...
  • Page 34 Indicators include CPOS port status indicator and subcard RDY indicator. Each CPOS interface has two status indicators (Link and Alarm). Table 5-5 Introduction to indicators on the front panel of FNM-2CPOS-STM1 Mark Note Description Status indicator of Off: The module is not electrified, it is not properly inserted, or functional module the module is removed;...
  • Page 35 type Interface SDH STM-1 standard Data rate 155.52Mbps Opti SDH155-SFP SDH155-SFP- SDH155-SFP-L SDH155-SFP-LH40-SM1310 -SX-MM850 SX-MM1310 H15-SM1310 Type Short-haul Short-haul Medium-haul Medium-haul single-mode multimode multimode single-mode opti Mini -10.0 dBm -20.0 dBm -15.0 dBm -5.0 dBm Maxi -4.0 dBm -14.0 dBm -8.0 dBm 0 dBm Receiver...
  • Page 36 The 4-port 155M POS interface module (FNM-4POS-STM1) must be used in conjunction with the carrier of RSR77-SIP1 module. One RSR77-SIP1 carrier module can support up to two FNM-4POS-STM1 functional modules. Image and Indicators Figure 5-3 Appearance of 4-port 155M POS interface module (FNM-4POS-STM1) Indicators include POS port status indicator and subcard RDY indicator.
  • Page 37 Protocols supported HDLC, PPP Interface standard GR-253-CORE (SONET)/ITUG.707 (SDH) DDR2 SDRAM 2 GB Electrostatic safety protection ESD 6 KV contact, 8 KV air Maximum power consumption ≤30 W Features Table 5-10 Technical specification of POS module interface Item Description Interface type SFP/LC Interface standard SDH STM-1...
  • Page 38 The module cables and SFP optical devices are sold separately. 1-port 155 M POS Interface Module (NME-1POS-STM1) The 1-port 155M POS interface module (NME-1POS-STM1) must be used in conjunction with the carrier of RSR77-SIP2 module. One RSR77-SIP2 carrier module can support up to two NME-1POS-STM1 functional modules.
  • Page 39 Table 5-11 Introduction to indicators on the front panel of NME-1POS-STM1 Mark Note Description Status indicator of Off: The module is not electrified, it is not properly functional module inserted, or the module is removed; Solid red: The module is abnormal; Solid green: The module has completed initialization and functions normally;...
  • Page 40 Type Short-haul Short-haul Medium-haul Medium-haul single-mode multimode multimode single-mode opti Mini -10.0 dBm -20.0 dBm -15.0 dBm -5.0 dBm Maxi -4.0 dBm -14.0 dBm -8.0 dBm 0 dBm Receiver -25.0 dBm -30.0 dBm -28.0 dBm -34.0 dBm sensitivity Overload -0 dBm -14 dBm -8.0 dBm -10.0 dBm...
  • Page 41 Indicators include the status indicator for each CE1 port and the subcard RDY indicator. Each CE1 port has one status indicators. Table 5-14 Introduction to indicators on the front panel of DNME-8E1/CE1 Mark Note Description Status indicator of Off: The line card is not electrified or not initialized; functional module Solid red: The module is abnormal;...
  • Page 42 Figure 5-6 Appearance of 6-port 100 M Ethernet module (NME-6FE) Table 5-16 Description of indicator state Mark State Description The line card is not electrified or not initialized; Solid red The module is abnormal. Solid green The indicator will be on after the line card is electrified and completes initialization.
  • Page 43 When NME-6FE module operates in forced mode (data rate forced to 10/100Mbps, and duplex mode forced to half/full duplex), only the crossover cable can be used. Table 5-18 Wiring sequence of standard network cable Orange/White Orange/White Orange Orange Green/White Green/White Blue Blue Blue/White...
  • Page 44 Solid green: The module has completed initialization and functions normally; Off: Connection not established; Link Port status indicator Solid green: The port has established connection with another network device; Malfunction alarm Off: Normal line communication; Alarm indicator Solid yellow: Abnormal line communication; Features ATM module provides ATM interface and supports 155 M standard SDH interface.
  • Page 45 opti Mini -10.0 dBm -20.0 dBm -15.0 dBm -5.0 dBm Maxi -4.0 dBm -14.0 dBm -8.0 dBm 0 dBm Receiver -25.0 dBm -30.0 dBm -28.0 dBm -34.0 dBm sensitivity Overload -0 dBm -14 dBm -8.0 dBm -10.0 dBm optical power Central 850nm 1310nm...

  • Page 46: Cable Types

    Solid green: The module has completed initialization and functions normally; Off: Connection not established; Link Port status indicator Solid green: The port has established connection with another network device; Features Table 5-24 lists the 4-port high-speed synchro serial interface module Item NME-4HS External interface...
  • Page 47 V.24DCE One end of the cable is DB25 female connector and the other end is DB26 male connector. Figure 5-10 V.24DCE Cable V.35DTE One end of the cable is DB34 male connector and the other end is DB26 male connector. Figure 5-11 V.35DTE Cable V.35DCE One end of the cable is DB34 male connector and the other end is DB26 male connector.
  • Page 48 V.35DTE. V.35 DTE/V.35 DCE is applicable to NMX-4HSH line card. In addition, Ruijie synchronous cards can be interconnected back to back through V.35DTE-V.35DCE cables in the laboratory. Table 5-26 Connection of the synchronous port of the router working in V.35 mode...
  • Page 49 NMX-4HSH NME-4HS Ruijie IPsec NME Encryption Module (DNME-SEC) Ruijie IPSEC NME Encryption Module DNME-SEC must be used in conjunction with the carrier of RSR77-SIP2 module. One RSR77-SIP2 carrier module can support one f DNME-SEC functional modules. The primary functions of DNME-SEC module are to provide SM1 grouping encryption algorithm to support the host platform and to generate true random numbers.
  • Page 50 8-port Gigabit Ethernet Fiber/Copper Combo Interface Module (DFNM-8GE) Including one model module: Eight GE interfaces and four of which support Fiber/Copper Combo. Image and Indicators Figure 5-10 Appearance of 8-port Gigabit Ethernet Fiber/Copper Combo Interface Module (DFNM-8GE) Indicators include the status indicator of each port and line card RDY indicator. Indicator: Link/ACT;...
  • Page 51 electrical interface adopts RJ45 connector, while the optical interface adopts SFP (Small Form-Factor Pluggable) module. The basic features are shown below: Table 5-29 Techincal specifications of DFNM-8GE Item DFNM-8GE High-speed multinuclear RISC processor BOOTROM 2 MB Flash Memory 512 MB DDR2 SDRAM 2 X 1 GB Fuse...
  • Page 52 DFNM-8GE module provides the following pluggable optical interface modules, which can be selected according to user's needs. Table 5-3 Pluggable optical interface modules Applicable Mini-GBIC-SX: single-port 1000BASE-SX mini GBIC conversion module (LC SFP modules interface); Mini-GBIC-LX: single-port 1000BASE-LX mini GBIC conversion module (LC interface);...
  • Page 53 Network 1000BASE-SX: wavelength 850 nm, medium and The maximum transmission range of 62.5/125um multi-mode fiber optic cable is maximum 220 m; The maximum transmission range of 50/125um multi-mode fiber optic cable is transmission range 500 m; 1000BASE-LX: wavelength 1310 nm, The maximum transmission range of 62.5/125um multi-mode fiber optic cable is 550 m;...

  • Page 54: Module Features

    Mark Note Description Status indicator of Off: The module is not electrified, it is not properly functional module inserted, or the module is removed; Solid red: The module is abnormal; Flashing green: The module is initializing; Solid green: The module has completed initialization and functions normally;...
  • Page 55 10GBASE-SR-XFP Multimode 62.5 33 m -7.5 Fiber (LC 22 m connector) 2000 300 m 82 m 66 m 10GBASE-LR-XFP 1310 Singlemode 10 km -4.8 -10.3 Fiber (LC connector) 10GBASE-ER-XFP 1550 Singlemode 40 km -1 -11.3 Fiber (LC connector) XG-XFP-ZR80-SM1550 1550 Singlemode 80 km 0 Fiber (LC connector)
  • Page 56 Indicators include the port status indicator and line card RDY indicator. Each fiber port has one status indicator (Link). Table 5-34 Introduction to indicators on the front panel of FNM-2XS Mark Note Description Status indicator of Off: The module is not electrified, it is not properly inserted, or functional module the module is removed;...
  • Page 57 Electrostatic safety ESD 6KV contact, 8KV air protection Maximum power consumption Cables The FNM-2XS module supports three types of SFP+ pluggable fiber module, which can be selected according to user’s’ needs. The basic features are shown below: Table 5-36 Pluggable fiber module model and specifications Wavelength Fiber type Inner Core...
  • Page 58 Mark Note Description Status indicator of Off: The module is not electrified, it is not properly inserted, or functional module the module is removed; Solid red: The module is abnormal; Blinking green: Initialization is in progress. Solid green: The module has completed initialization and functions normally;...
  • Page 59 Electrostatic safety ESD 6KV contact, 8KV air protection Maximum power consumption Cables FNM-8GE module supports the following pluggable fiber modules, which can be selected according to user’s needs. Table 5-39 Pluggable fiber modules Available SFP Mini-GBIC-SX: single-port 1000BASE-SX mini GBIC conversion module (LC modules interface);...
  • Page 60 Network medium 1000BASE-SX: wavelength 850 nm, and maximum The maximum transmission range of 62.5/125um multi-mode fiber optic cable is transmission 220 m; The maximum transmission range of 50/125um multi-mode fiber optic cable is 500 range 1000BASE-LX: wavelength 1310 nm, The maximum transmission range of 62.5/125um multi-mode fiber optic cable is 550 m;...
  • Page 61 Mark Note Description Status indicator of Off: The module is not electrified, it is not properly inserted, or functional module the module is removed; Solid red: The module is abnormal; Blinking green: Initialization is in progress. Solid green: The module has completed initialization and functions normally;...
  • Page 62 protection Electrostatic safety ESD 6KV contact, 8KV air protection Maximum power 100W consumption Cables DFNM-32GT/16SFP module supports the following pluggable fiber modules, which can be selected according to user’s needs. Table 5-43 Pluggable fiber modules Available SFP Mini-GBIC-GT: single-port 10/100/1000BASE-GT mini GBIC conversion module modules (RJ45 interface);...
  • Page 63 Network medium 1000BASE-SX: wavelength 850 nm, and maximum The maximum transmission range of 62.5/125um multi-mode fiber optic cable is transmission 220 m; The maximum transmission range of 50/125um multi-mode fiber optic cable is 500 range 1000BASE-LX: wavelength 1310 nm, The maximum transmission range of 62.5/125um multi-mode fiber optic cable is 550 m;...
  • Page 64 Status indicator of Off: The module is not electrified, it is not properly inserted, or functional module the module is removed; Solid red: The module is abnormal; Blinking green: Initialization is in progress. Solid green: The module has completed initialization and functions normally;...
  • Page 65 Available SFP Mini-GBIC-GT: single-port 10/100/1000BASE-GT mini GBIC conversion module modules (RJ45 interface); Mini-GBIC-SX: single-port 1000BASE-SX mini GBIC conversion module (LC interface); Mini-GBIC-LX: single-port 1000BASE-LX mini GBIC conversion module (LC interface); Mini-GBIC-LH40: single-port 1000BASE-LH mini GBIC conversion module (LC interface), 40 km; Mini-GBIC-ZX50: single-port 1000BASE-ZX mini GBIC conversion module (LC interface), 50 km;...
  • Page 66 Network medium 1000BASE-SX: wavelength 850 nm, and maximum The maximum transmission range of 62.5/125um multi-mode fiber optic cable is transmission 220 m; The maximum transmission range of 50/125um multi-mode fiber optic cable is 500 range 1000BASE-LX: wavelength 1310 nm, The maximum transmission range of 62.5/125um multi-mode fiber optic cable is 550 m;...
  • Page 67 Indicators include POS/CPOS interface status indicator and line card RDY indicator. Each POS/CPOS interface has two status indicators (Link/Alarm). Table 5-49 Introduction to indicators on the front panel of FNM-1CPOS-STM16/4CPOS-STM4 Mark Note Description Status indicator of Off: The module is not electrified, it is not properly inserted, or functional module the module is removed;...
  • Page 68 protection Maximum power ≤50W consumption Table 5-51 Specifications of FNM-1CPOS-STM16/4CPOS-STM4 module interface Item Description Interface type SFP/LC Interface SDH STM-1 standard Data rate 155.52Mbps Optical SDH155-SFP-SX SDH155-SFP-SX- SDH155-SFP-LH15- SDH155-SFP-LH40 Module Model -MM850 MM1310 SM1310 -SM1310 Type Short-haul Short-haul Medium-haul Medium-haul multimode multimode single-mode...
  • Page 69 Overload optical -8.0 dBm -8.0 dBm -8.0 dBm power Central wavelength 1310nm 1310nm 1550nm Maximum 15km 40km 80km transmission distance Fiber type 9/125um 9/125um 9/125um Item Description Interface type SFP/LC Interface SDH STM-16 standard Data rate 2488.32Mbps Optical SDH2.5G-SFP-SX SDH2.5G-SFP-LH1 SDH2.5G-SFP-LH4 SDH2.5G-SFP-LH8 Module...
  • Page 70 RG-PA300I power supply module. RSR7704 router supports up to two RG-PA300I power supply modules. To ensure the normal operation of your device, 1+1 power supply redundancy is recommended. RSR7708 router supports up to three RG-PA300I power supply modules. To ensure the normal operation of your device, N+1 power supply redundancy is recommended.
  • Page 71 N+1 redundant backup mode indicates that N power supply modules are needed to ensure normal operation of the system. Among those N power supply modules, if any module fails, one of the standby power supply modules will immediately take over the role of the damaged power supply module without affecting system operation.
  • Page 72 Rated output +12V :0-48.2 A 12 VFAN :0-6 A Maximum power 650 W Hot swap Supported N+N backup The system supports N+N redundant backup. RSR7704/08 supports 1+1 redundancy, while RSR7716 supports 2+2 redundancy. Power-factor correction Supported Protection Input overvoltage protection, under-voltage protection, output overvoltage protection, over-current protection, short-circuit protection, overheat protection N+N redundant backup mode indicates that N power supply modules are needed to ensure...
  • Page 73 Maximum power 40 W Item RSR7704-FAN V1.10 Dimension 376 mm × 28.4 mm × 215.2 mm ( L x W x H mm) Fan number Rotational speed 4000RPM Blast volume 280CFM(1.30 m3/min) Maximum power 40 W Remarks: Chassis of V1.1X and later use the fan of V1.10, while chassis of V1.0X uses the fan of V1.00. RSR7708-FAN Fan Tray Module Image and Indicators Figure 7-2 Appearance of RSR7708-FAN fan tray module...

  • Page 74: Rich Protocol Support

    Remarks: Chassis of V1.1X and later use the fan of V1.10, while V1.0X chassis uses the fan of V1.00. RSR7716-FAN Fan Tray Module Image and Indicators Figure 7-3 Appearance of RSR7716-FAN fan tray module Power indicator: Solid green indicates normal power supply to the fan tray, while solid red indicates abnormal power supply to the fan tray.

  • Page 75: Friendly User Interface

     Supports MPLS protocol, the two- and three-layer VPN service, forming powerful MPLS network with other Ruijie web products providing high-performance, safe and multi-level MPLS VPN solutions.  Supports high reliability, high capacity, high performance VPDN/MSTP convergence ability, cross-VPN multicast and dual hot-standby scheme.

  • Page 76: High Security

    High Security  IP packet filtering technologies for strict inspection by network address, port number, or protocol type AAA and RADIUS authentication   PPP-based PAP and CHAP and callback function to enhance the security and reliability of communications  Hierarchical password check and security logs ...

  • Page 77: Chapter 2 Preparation For Installation

     Use UPS to prevent power failure and other interferences Preparing Installation Site Ruijie routers are for indoor use only. To ensure their normal operation and prolong their life span, the installation site should meet the following requirement:  Temperature and humidity Requirements ...
  • Page 78 The electrostatic attraction is easier to occur when the relative humility is low. The following table gives Ruijie routers' requirements on dusts density and diameter in equipment room. Maximum diameter (µm) Maximum content (number of 1.4 x 10...

  • Page 79: Lightning Protection

     Use electromagnetic shielding means when necessary. Lightning Protection Ruijie families of routers are designed with lightning protection. But as an electrical device, it may be damaged by strong lightning strike. Therefore, you need do the following:  Ensure good contact between the grounding cable of the router and the ground.
  • Page 80 Configuration cables  Ethernet cables  Module interface cables The power cables, configuration cables and connectors are supplied along with Ruijie routers. The Ethernet cables and module interface cables need be purchased separately. The relative devices include:  Hub or switch ...

  • Page 81: Installation Flowchart

    Chapter 3 Installing the Router Installation Flowchart Please follow the following procedure to install the router to ensure the smooth installation and avoid any damage to the unit:...

  • Page 82: Fastening The Router

    Fastening the Router Now the router is ready for installation. Mount it to either of these two places.  A cabinet  A workbench Mounting on the Rack RSR77 series routers are designed for 19-inch standard cabinets. Use the supplied fixing accessory for installation when needed.
  • Page 83 In Step 4 be careful and drive the power module gently and smoothly. If you find the module hard to drive, never drive it hard. Instead, remove the power module and check the power module is flush with the edge of the opening of the back panel. If it is, continue the operation. Otherwise the module may be damaged.
  • Page 84 Installing Fan Tray Module Installing Router Fan Tray Module This part applies to the installation of the RSR77 series routers. The modules to be installed are the RSR7704-FAN, RSR7708-FAN and RSR7716-FAN fan tray module. Place the router in such a way that you face the front panel of its host. Place the fan tray module in such a way that the power indicator of the fan is on the topside, namely the sequence number on the fan panel is ascending from bottom to top.
  • Page 85 If it is, continue the operation. Otherwise the module may be damaged. Installing Power Cable and Grounding Cable Ruijie RSR77 Series Routers Support the Following AC Power Supply AC: 100–240 V~; 50/60 Hz Make sure that your power supply meets the requirement.

  • Page 86: Connecting Console

    Install the protective cover and fasten the screws. Connect the other end of power cable with the corresponding socket or connector. Connecting Console Ruijie series routers supply an EIA/TIA-232 configuration console for local configuration. Table 7-1 Attributes of the configuration console Parameter...

  • Page 87: Installing Line Card

    Installing Line card Installation in this part is for the line card module with powered off. The line card module includes the carrier module and functional module. For details on hot swap, refer to the software manual. Installing Line card Place the router in such a way that its front panel faces you.
  • Page 88 Removing Line Card Place the router in such a way that its back panel faces you. Unplug the interface cable of the module to be removed. Remove the fastening screws at either side of the interface board of the line card module with a cross screwdriver.
  • Page 89 Troubleshooting If you find the router fails to operate after you have installed line card modules, check the points listed below.  The interface cable of each module matches.  Observe the interface indicator of each module. Decide whether the module is operating normally. ...

  • Page 90: Chapter 4 Starting And Configuring The Router

    Chapter 4 Starting and Configuring the Router Starting a Router Setting Up the Configuration Environment When you use the router for the very first time, you will need to configure the router through a console port as follows: As shown in the following figure, connect the serial port of a character terminal or microcomputer to the console port through a RS232 cable.
  • Page 91 Set communication parameters for the serial port. Select a terminal emulation type.
  • Page 92 When you have finished building the configuration environment, you may power on the router. Powering up the Router Verification before Power-up Before powering on the router, please check  If the power cable and the grounding cable are connected correctly. ...

  • Page 93: Verification After Power-Up

    CLOCK-3-HW_CAL_INVALID: Hardware Calendar (RTC) Error. MTD_DRIVER-5-MTD_NAND_FOUND: 1 NAND chips(chip size : 536870912) detected MTD_DRIVER-5-MTD_NAND_FOUND: 1 nand chip(s) found on the target.*Jan 1 00:45:53: %SYS-5-WARMSTART: System warmstart. Ruijie> Such information may vary with hardware configuration or software version. Now the router is ready for configuration.

  • Page 94: Configuring The Router

    When using the router for the first time, it is recommended setting basic parameters using the configuration function. Configuring the Router Before using the router, you will have to configure it as needed. For more information on router configuration, see the related Configuration Guide and Command Reference.

  • Page 95: Chapter 5 Troubleshooting

    Chapter 5 Troubleshooting Power Troubleshooting For the RSR77 series routers, you may use the power indicator on the front panel and the status indicator on the power module to decide if the power supply system is operating normally. For description of indicators, see Chapter 1.

  • Page 96: Fan Troubleshooting

    Fan Troubleshooting For the RSR77 series routers, you may use the FAN indicator on the SRCMI mater control module and the Power status indicators on the fan module to decide if the fan module is operating normally. For description of indicators, see Chapter 1. If a fault occurs, check ...
