Ruijie RSR10 Series Hardware Installation Manual page 104

Chapter 6 Cable Connection
8AE34-11--
8AE38-11--
8AE39-11--
39165-11--
8AE86-11--
8AE87-11--
6-6
ADAPTER/RJ45F-DB25F
CAB-E1 UNBALANCED/DB9M-2*BNC/75
OHM/3M
CAB-E1 BALANCED/DB9M-RJ45M/120
OHM/3M
CAB-E1 BALANCED/DB9M-RJ45F/120
OHM/3M
CAB-E1 UNBALANCED/DB25M-8*BNC/75
OHM/3M
CAB-E1 BALANCED/DB25M-4*RJ45M/120
OHM/3M
Installation Manual
converter
RJ45(crystal jack)-DB25
female converter
Non-balanced cable
Balanced cable(
connector interface)
Balanced cable( crystal jack
interface)
4E1 non-balanced cable
4E1 balanced cable
crystal
