Step 1 Open the SIM slot according to the indicated OPEN direction.

Step 2 Insert the SIM card into the slot.

Step 3 Close the slot in the opposite direction of OPEN.

Figure: SIM slot

Note

1.3.14

Other SIC Cards

Ruijie Networks currently provides the following SIC cards: SIC-4ESW, SIC-1HS, ,

SIC-1E1-F, SIC-1HS-V35, SIC-1B-U, SIC-1B-S/T, SIC-8A, SIC-1A, SIC-2FXS, SIC-2FXO,

and SIC-1CE1, SIC-3G-TD, SIC-3G-CDMA and SIC-3G-WCDMA. The descriptions of the

subsequent SIC cards will be updated in this document as the cards are launched.

1.4

1.4.1

NMX card model: NMX-24ESW

1. The gap of the SIM card should be aligned with that of the SIM slot. In this

manner, the SIM card can be installed correctly.

2. The SIM slot should be closed when there is no SIM card in it. Otherwise,

there are risks of damaging the SIM slot.

Chapter 1 Product Overview

1-57
