3Com Complement
Attendant Software
Configuring the 3Com 2102 Telephone without a DHCP Server
If your network does not use a DHCP server to provide IP addresses to
devices, you must manually configure the IP address of the 3Com 2102
Business Telephone.
1 Configure the telephone as described in
Telephone with a DHCP Server"
disconnect and reconnect the power as described in the final step.
2 Press the Program button, located below the up and down arrow
buttons.
3 Press 2 (Set MY IP).
4 Enter the IP address that you want to assign to the telephone.
5 Press # to save the new setting.
6 Press 3 (Set SubNMsk).
7 Enter the subnetwork mask appropriate for the subnetwork to which the
telephone is connected.
8 Press # to save the new setting.
9 Press 4 (Set GatwyIP).
10 Enter the IP address of the gateway for this subnetwork.
11 Press # to save the new setting.
12 Disconnect and reconnect the telephone power cord.
The telephone contacts the primary Call Processor server and begins to
download the appropriate software.
During the downloading process, several progress messages appear in
the telephone display panel. After the software has been downloaded to
the telephone, the message "Local Phone Number:" appears.
To log in on the telephone, a user enters:
An extension number, followed by #
■
A numeric password, followed by #
■
The Complement Attendant Console is a software application that you
install on a PC that is running Windows 98, Windows 2000, or Windows
XP software. After the software has been installed, you must configure
Telephone Installation
"Configuring the 3Com 2102
earlier in this section, but do not
99
