48 C 2: I
HAPTER NSTALLATION
Sample UMS
Installation Script
(Secondary Server)
Type of VCX 7300 Installation (S-Standalone/C-Client/V-Server)? [S]
Number of voip ports? [144]
IP address of the outbound proxy? [10.20.30.43]
Name of the SIP DDD?
TCP/UDP Port on which the VCX 7300 will receive SIP messages [5060] 5060
IP address of the secondary proxy? (hit Enter if none) [ ] 10.20.30.41
Intelligent Mirroring configurations
Should Intelligent Mirroring be enabled (Y/N)?
Enter the Device Name of the Network Card to be used by UMS?
Enter the Device Name of the Second Network Card to be used by UMS, press ENTER if
only one? :
Name of the Remote Intelligent Mirrored system? [ ] vcx01
S S P
CRIPTS FOR A INGLE AIR OF
After the network installation script has been completed, the UMS
installation script starts.
Press the Enter or Return key to accept Standalone as the suggested
answer.
Press the Enter or Return key to accept the default number (144) of VOIP
ports that the system will support. Do not enter a different value without
consulting 3Com.
Outbound Proxy is another name for the Call Processor. Enter the IP
address of the primary VCX Call Processor.
[10.20.30.43]
The SIP Default Dialing Domain software runs on the same server as the
VCX Call Processor. Press the Enter or Return key to accept the IP address
of the primary VCX Call Processor.
Press the Enter or Return key to accept 5060 as the suggested answer.
The VCX Call Processor and UMS use the same port number but on
different IP addresses.
Enter the IP address of the secondary VCX Call Processor server
(10.20.30.43 in this sample configuration that contains a single pair of
servers).
All supported UMS configurations require Intelligent Mirroring. Enter y.
Press the Enter or Return key to indicate that UMS uses only the eth0
network card.
Enter the name of the active UMS server (vcx01 in this example).
S
ERVERS
UMS Installation Script — Secondary Server
[N]: y
: eth0
