92 C 5: I
HAPTER NSTALLING
D
EVICES
Configuring the 3Com 3101 Telephone without a DHCP Server
If your network does not use a DHCP server to provide IP addresses to
devices, you must manually configure the IP address of the 3Com 3101
Basic Telephone.
1 Configure the telephone as described in
Telephone with a DHCP Server"
disconnect and reconnect the power as described in the final step.
2 Press the Select button, located in the center of the four arrow buttons.
3 Press 2 (Set My IP).
4 Enter the IP address that you want to assign to the telephone.
5 Press # to save the new setting.
6 Press 3 (Set SubNMsk).
7 Enter the subnetwork mask appropriate for the subnetwork to which the
telephone is connected.
8 Press # to save the new setting.
9 Press 4 (Set GatwyIP).
10 Enter the IP address of the gateway for this subnetwork.
11 Press # to save the new setting.
12 Disconnect and reconnect the telephone power cord.
The telephone contacts the primary Call Processor server and begins to
download the appropriate software.
During the downloading process, several progress messages appear in
the telephone display panel. After the software has been downloaded to
the telephone, the message "Local Phone Number:" appears.
To log in on the telephone, a user enters:
An extension number, followed by #
■
A numeric password, followed by #
■
To assign a telephone extension to a user, you must configure the
telephone extension number and user ID using the VCX Administrator
User Interface. For information about how to perform these tasks, refer
to the VCX Administration Guide.
"Configuring the 3Com 2101
earlier in this section, but do not
