122 A A: C
PPENDIX ONFIGURING
Creating
Option 184
O 184 W
PTION ON A
To help you configure option 184, this appendix includes an example of
how to configure option 184 on a Windows 2000 server that has been
configured to run DHCP server software. It covers these topics:

Creating Option 184

■
Editing Option 184 Values
■
Activating Option 184
■
The information in this appendix pertains only to a Windows 2000 server.
The configuration instructions differ for other DHCP servers. See the
documentation for your DHCP server for instructions.
This appendix describes only the configuration of option 184, not how to
install or perform basic configuration of the Windows 2000 server.
If you are configuring more than one suboption for Option 184, the first
subfield must be the NCP IP Address for backward compatibility.
If you configure multiple suboptions, 3Com recommends that you
configure them in order of suboption number. You can omit one or more
suboptions from the configuration. For example, if you decide not to
configure suboption 2, 3Com recommends that you configure
suboptions 1, 3, and 4, in that order.
1 Start the DHCP Microsoft Management Console:
Start > Programs > Administrative Tools > DHCP
The DHCP dialog box appears. In the left pane, look for the name of your
Windows 2000 DHCP server.
2 Right click the name of your DHCP server. From the menu that appears,
select Set Predefined Options to open the Predefined Options and Values
dialog box.
3 Click Add to open the Option Type dialog box.
4 In the Name field, type a name of your choice.
5 From the Data Type drop-down list, select Byte.
6 Enable the Array check box.
7 In the Code text box, type 184.
8 In the Description text box, enter a description of your choice. Example:
VCX NCP IP Address.
