3Com 2102
Business Telephone
7 Enter the subnetwork mask appropriate for the subnetwork to which the
telephone is connected.
8 Press # to save the new setting.
9 Press 4 (Set GatwyIP).
10 Enter the IP address of the gateway for this subnetwork.
11 Press # to save the new setting.
12 Disconnect and reconnect the telephone power cord.
The telephone contacts the primary Call Processor server and begins to
download the appropriate software.
During the downloading process, several progress messages appear in
the telephone display panel. After the software has been downloaded to
the telephone, the message "Local Phone Number:" appears.
To log in on the telephone, a user enters:
An extension number, followed by #
■
A numeric password, followed by #
■
The easiest way to install any 3Com telephone assumes that the
telephone obtains an IP address from a DHCP server. If your network does
not provide IP addresses through a DHCP server, you must manually
configure the IP address of the telephone.
Configuring the 3Com 2102 Telephone with a DHCP Server
To configure the 3Com 2102 Business Telephone:
CAUTION: Do not connect an Ethernet cable to the telephone until after
you have configured the IP address of the primary and alternate VCX Call
Processors.
1 Plug the power cord into an AC power receptacle.
2 Plug the other end of the power cord into the power connector on the
telephone.
3 Press the Program button, located below the up and down arrow
buttons.
4 Press 5 (Set NCP IP).
5 Enter the IP address of the primary VCX Call Processor.
Telephone Installation 97
