UM1940
DMA mode IO operation
Send an amount of data in non blocking mode (DMA) using
HAL_UART_Transmit_DMA()
At transmission end of half transfer HAL_UART_TxHalfCpltCallback is executed and
user can add his own code by customization of function pointer
HAL_UART_TxHalfCpltCallback
At transmission end of transfer HAL_UART_TxCpltCallback is executed and user can
add his own code by customization of function pointer HAL_UART_TxCpltCallback
Receive an amount of data in non blocking mode (DMA) using
HAL_UART_Receive_DMA()
At reception end of half transfer HAL_UART_RxHalfCpltCallback is executed and user
can add his own code by customization of function pointer
HAL_UART_RxHalfCpltCallback
At reception end of transfer HAL_UART_RxCpltCallback is executed and user can
add his own code by customization of function pointer HAL_UART_RxCpltCallback
In case of transfer Error, HAL_UART_ErrorCallback() function is executed and user
can add his own code by customization of function pointer HAL_UART_ErrorCallback
Pause the DMA Transfer using HAL_UART_DMAPause()
Resume the DMA Transfer using HAL_UART_DMAResume()
Stop the DMA Transfer using HAL_UART_DMAStop()
UART HAL driver macros list
Below the list of most used macros in UART HAL driver.
__HAL_UART_ENABLE: Enable the UART peripheral
__HAL_UART_DISABLE: Disable the UART peripheral
__HAL_UART_GET_FLAG : Check whether the specified UART flag is set or not
__HAL_UART_CLEAR_FLAG : Clear the specified UART pending flag
__HAL_UART_ENABLE_IT: Enable the specified UART interrupt
__HAL_UART_DISABLE_IT: Disable the specified UART interrupt
__HAL_UART_GET_IT_SOURCE: Check whether the specified UART interrupt has
occurred or not
47.2.2
Initialization and Configuration functions
This subsection provides a set of functions allowing to initialize the USARTx or the UARTy
in asynchronous mode.
For the asynchronous mode only these parameters can be configured:
You can refer to the UART HAL driver header file for more useful macros
Baud Rate
Word Length
Stop Bit
Parity: If the parity is enabled, then the MSB bit of the data written in the data
register is transmitted but is changed by the parity bit. Depending on the frame
length defined by the M bit (8-bits or 9-bits), please refer to Reference manual for
possible UART frame formats.
Hardware flow control
Receiver/transmitter modes
Over Sampling Method
DocID028236 Rev 2
HAL UART Generic Driver
649/1371
