UM1940
LL_ADC_AWD_CH_VBAT_REG
LL_ADC_AWD_CH_VBAT_INJ
LL_ADC_AWD_CH_VBAT_REG_INJ
LL_ADC_AWD_CH_TEMPSENSOR_REG
LL_ADC_AWD_CH_TEMPSENSOR_INJ
LL_ADC_AWD_CH_TEMPSENSOR_REG_INJ
Analog watchdog - Analog watchdog number
LL_ADC_AWD1
Analog watchdog - Thresholds
LL_ADC_AWD_THRESHOLD_HIGH
LL_ADC_AWD_THRESHOLD_LOW
ADC instance - Channel number
LL_ADC_CHANNEL_0
LL_ADC_CHANNEL_1
LL_ADC_CHANNEL_2
LL_ADC_CHANNEL_3
LL_ADC_CHANNEL_4
ADC analog watchdog number 1
ADC analog watchdog threshold high
ADC analog watchdog threshold low
ADC external channel (channel connected to GPIO
pin) ADCx_IN0
ADC external channel (channel connected to GPIO
pin) ADCx_IN1
ADC external channel (channel connected to GPIO
pin) ADCx_IN2
ADC external channel (channel connected to GPIO
pin) ADCx_IN3
ADC external channel (channel connected to GPIO
DocID028236 Rev 2
LL ADC Generic Driver
converted by either group regular or
injected
ADC analog watchdog monitoring of
ADC internal channel connected to
Vbat/3: Vbat voltage through a divider
ladder of factor 1/3 to have Vbat always
below Vdda, converted by group regular
only
ADC analog watchdog monitoring of
ADC internal channel connected to
Vbat/3: Vbat voltage through a divider
ladder of factor 1/3 to have Vbat always
below Vdda, converted by group injected
only
ADC analog watchdog monitoring of
ADC internal channel connected to
Vbat/3: Vbat voltage through a divider
ladder of factor 1/3 to have Vbat always
below Vdda
ADC analog watchdog monitoring of
ADC internal channel connected to
Temperature sensor, converted by group
regular only
ADC analog watchdog monitoring of
ADC internal channel connected to
Temperature sensor, converted by group
injected only
ADC analog watchdog monitoring of
ADC internal channel connected to
Temperature sensor, converted by either
group regular or injected
