HAL DCMI Generic Driver

14.1

DCMI Firmware driver registers structures

14.1.1

DCMI_CodesInitTypeDef

Data Fields
uint8_t FrameStartCode
uint8_t LineStartCode
uint8_t LineEndCode
uint8_t FrameEndCode
Field Documentation
uint8_t DCMI_CodesInitTypeDef::FrameStartCode
Specifies the code of the frame start delimiter.
uint8_t DCMI_CodesInitTypeDef::LineStartCode
Specifies the code of the line start delimiter.
uint8_t DCMI_CodesInitTypeDef::LineEndCode
Specifies the code of the line end delimiter.
uint8_t DCMI_CodesInitTypeDef::FrameEndCode
Specifies the code of the frame end delimiter.
14.1.2

DCMI_InitTypeDef

Data Fields
uint32_t SynchroMode
uint32_t PCKPolarity
uint32_t VSPolarity
uint32_t HSPolarity
uint32_t CaptureRate
uint32_t ExtendedDataMode
DCMI_CodesInitTypeDef SyncroCode
uint32_t JPEGMode
Field Documentation
uint32_t DCMI_InitTypeDef::SynchroMode
Specifies the Synchronization Mode: Hardware or Embedded. This parameter can be
a value of
uint32_t DCMI_InitTypeDef::PCKPolarity
Specifies the Pixel clock polarity: Falling or Rising. This parameter can be a value of
DCMI_PIXCK_Polarity
uint32_t DCMI_InitTypeDef::VSPolarity
Specifies the Vertical synchronization polarity: High or Low. This parameter can be a
value of
uint32_t DCMI_InitTypeDef::HSPolarity
Specifies the Horizontal synchronization polarity: High or Low. This parameter can be
a value of
uint32_t DCMI_InitTypeDef::CaptureRate
Specifies the frequency of frame capture: All, 1/2 or 1/4. This parameter can be a
value of
DCMI_Synchronization_Mode
DCMI_VSYNC_Polarity
DCMI_HSYNC_Polarity
DCMI_Capture_Rate
