uint32_t DCMI_InitTypeDef::ExtendedDataMode
Specifies the data width: 8-bit, 10-bit, 12-bit or 14-bit. This parameter can be a value
of DCMI_Extended_Data_Mode
DCMI_CodesInitTypeDef DCMI_InitTypeDef::SyncroCode
Specifies the code of the frame start delimiter.
uint32_t DCMI_InitTypeDef::JPEGMode
Enable or Disable the JPEG mode. This parameter can be a value of
DCMI_MODE_JPEG
14.1.3

DCMI_HandleTypeDef

Data Fields
DCMI_TypeDef * Instance
DCMI_InitTypeDef Init
HAL_LockTypeDef Lock
__IO HAL_DCMI_StateTypeDef State
__IO uint32_t XferCount
__IO uint32_t XferSize
uint32_t XferTransferNumber
uint32_t pBuffPtr
DMA_HandleTypeDef * DMA_Handle
__IO uint32_t ErrorCode
Field Documentation
DCMI_TypeDef* DCMI_HandleTypeDef::Instance
DCMI Register base address
DCMI_InitTypeDef DCMI_HandleTypeDef::Init
DCMI parameters
HAL_LockTypeDef DCMI_HandleTypeDef::Lock
DCMI locking object
__IO HAL_DCMI_StateTypeDef DCMI_HandleTypeDef::State
DCMI state
__IO uint32_t DCMI_HandleTypeDef::XferCount
DMA transfer counter
__IO uint32_t DCMI_HandleTypeDef::XferSize
DMA transfer size
uint32_t DCMI_HandleTypeDef::XferTransferNumber
DMA transfer number
uint32_t DCMI_HandleTypeDef::pBuffPtr
Pointer to DMA output buffer
DMA_HandleTypeDef* DCMI_HandleTypeDef::DMA_Handle
Pointer to the DMA handler
__IO uint32_t DCMI_HandleTypeDef::ErrorCode
DCMI Error code
14.2

DCMI Firmware driver API description

14.2.1

How to use this driver

The sequence below describes how to use this driver to capture image from a camera
module connected to the DCMI Interface. This sequence does not take into account the
configuration of the camera module, which should be made before to configure and enable
the DCMI to capture images.
