UM1940
Return values

HAL_DACEx_DualSetValue

Function name
Function description
Parameters
Return values
Notes

HAL_DACEx_ConvCpltCallbackCh2

Function name
Function description
Parameters
DAC_LFSRUNMASK_BITS2_0: Unmask DAC channel
LFSR bit[2:0] for noise wave generation
DAC_LFSRUNMASK_BITS3_0: Unmask DAC channel
LFSR bit[3:0] for noise wave generation
DAC_LFSRUNMASK_BITS4_0: Unmask DAC channel
LFSR bit[4:0] for noise wave generation
DAC_LFSRUNMASK_BITS5_0: Unmask DAC channel
LFSR bit[5:0] for noise wave generation
DAC_LFSRUNMASK_BITS6_0: Unmask DAC channel
LFSR bit[6:0] for noise wave generation
DAC_LFSRUNMASK_BITS7_0: Unmask DAC channel
LFSR bit[7:0] for noise wave generation
DAC_LFSRUNMASK_BITS8_0: Unmask DAC channel
LFSR bit[8:0] for noise wave generation
DAC_LFSRUNMASK_BITS9_0: Unmask DAC channel
LFSR bit[9:0] for noise wave generation
DAC_LFSRUNMASK_BITS10_0: Unmask DAC channel
LFSR bit[10:0] for noise wave generation
DAC_LFSRUNMASK_BITS11_0: Unmask DAC channel
LFSR bit[11:0] for noise wave generation
HAL: status
HAL_StatusTypeDef HAL_DACEx_DualSetValue
(DAC_HandleTypeDef * hdac, uint32_t Alignment, uint32_t
Data1, uint32_t Data2)
Set the specified data holding register value for dual DAC channel.
hdac: pointer to a DAC_HandleTypeDef structure that
contains the configuration information for the specified DAC.
Alignment: Specifies the data alignment for dual channel
DAC. This parameter can be one of the following values:
DAC_ALIGN_8B_R: 8bit right data alignment selected
DAC_ALIGN_12B_L: 12bit left data alignment selected
DAC_ALIGN_12B_R: 12bit right data alignment selected
Data1: Data for DAC Channel2 to be loaded in the selected
data holding register.
Data2: Data for DAC Channel1 to be loaded in the selected
data holding register.
HAL: status
In dual mode, a unique register access is required to write in
both DAC channels at the same time.
void HAL_DACEx_ConvCpltCallbackCh2
(DAC_HandleTypeDef * hdac)
Conversion complete callback in non blocking mode for Channel2.
hdac: pointer to a DAC_HandleTypeDef structure that
contains the configuration information for the specified DAC.
DocID028236 Rev 2
HAL DAC Extension Driver
173/1371
