ST STM32F2 User Manual page 205

UM1940
uint32_t ETH_MACInitTypeDef::AutomaticPadCRCStrip
Selects or not the Automatic MAC Pad/CRC Stripping. This parameter can be a value
of ETH_Automatic_Pad_CRC_Strip
uint32_t ETH_MACInitTypeDef::BackOffLimit
Selects the BackOff limit value. This parameter can be a value of
ETH_Back_Off_Limit
uint32_t ETH_MACInitTypeDef::DeferralCheck
Selects or not the deferral check function (Half-Duplex mode). This parameter can be
a value of
uint32_t ETH_MACInitTypeDef::ReceiveAll
Selects or not all frames reception by the MAC (No filtering). This parameter can be a
value of
uint32_t ETH_MACInitTypeDef::SourceAddrFilter
Selects the Source Address Filter mode. This parameter can be a value of
ETH_Source_Addr_Filter
uint32_t ETH_MACInitTypeDef::PassControlFrames
Sets the forwarding mode of the control frames (including unicast and multicast
PAUSE frames) This parameter can be a value of
uint32_t ETH_MACInitTypeDef::BroadcastFramesReception
Selects or not the reception of Broadcast Frames. This parameter can be a value of
ETH_Broadcast_Frames_Reception
uint32_t ETH_MACInitTypeDef::DestinationAddrFilter
Sets the destination filter mode for both unicast and multicast frames. This parameter
can be a value of
uint32_t ETH_MACInitTypeDef::PromiscuousMode
Selects or not the Promiscuous Mode This parameter can be a value of
ETH_Promiscuous_Mode
uint32_t ETH_MACInitTypeDef::MulticastFramesFilter
Selects the Multicast Frames filter mode:
None/HashTableFilter/PerfectFilter/PerfectHashTableFilter. This parameter can be a
value of
uint32_t ETH_MACInitTypeDef::UnicastFramesFilter
Selects the Unicast Frames filter mode:
HashTableFilter/PerfectFilter/PerfectHashTableFilter. This parameter can be a value
of ETH_Unicast_Frames_Filter
uint32_t ETH_MACInitTypeDef::HashTableHigh
This field holds the higher 32 bits of Hash table. This parameter must be a number
between Min_Data = 0x0 and Max_Data = 0xFFFFFFFF
uint32_t ETH_MACInitTypeDef::HashTableLow
This field holds the lower 32 bits of Hash table. This parameter must be a number
between Min_Data = 0x0 and Max_Data = 0xFFFFFFFF
uint32_t ETH_MACInitTypeDef::PauseTime
This field holds the value to be used in the Pause Time field in the transmit control
frame. This parameter must be a number between Min_Data = 0x0 and Max_Data =
0xFFFF
uint32_t ETH_MACInitTypeDef::ZeroQuantaPause
Selects or not the automatic generation of Zero-Quanta Pause Control frames. This
parameter can be a value of
uint32_t ETH_MACInitTypeDef::PauseLowThreshold
This field configures the threshold of the PAUSE to be checked for automatic
retransmission of PAUSE Frame. This parameter can be a value of
ETH_Pause_Low_Threshold
uint32_t ETH_MACInitTypeDef::UnicastPauseFrameDetect
Selects or not the MAC detection of the Pause frames (with MAC Address0 unicast
ETH_Deferral_Check
ETH_Receive_All
ETH_Destination_Addr_Filter
ETH_Multicast_Frames_Filter
ETH_Zero_Quanta_Pause
DocID028236 Rev 2
HAL ETH Generic Driver
ETH_Pass_Control_Frames
205/1371
