▼ To Remove the Line Card Filler Panels

Your Sun Datacenter Switch 3456 might ship with line card filler panels installed.
You must remove the filler panel where a line card will install.
1. Grasp the locking levers at each end of the filler panel.
See
FIGURE 6-3
2. Turn the levers counter-clockwise to the unlocked position.
See
3. Pull the filler panel away from the chassis by the handles.
See
40 Sun Datacenter Switch 3456 Installation Guide • December 2008
.
FIGURE 6-3
Turning Filler Panel Lock Levers
.
FIGURE 6-3
.
FIGURE 6-4
