Sun Datacenter Switch 3456 Installation Sequence (Continued)
TABLE 4-1
Step Task
8 Inspect midplane back pins. Repair or replace them if
necessary.
9 Install midplane stiffener.
10 Install fabric cards.
11 Remove midplane stiffener.
12 Inspect midplane front pins. Repair or replace them if
necessary.
13 Install line cards.
14 Install filler panels in any vacant slots.
15 Install cable trees and cable plates.
16 Install additional power supplies.
17 Attach power cables.
18 Configure the CMC.
19 Power up the power supplies.
20 Power on the fabric cards and line cards.
21 Verify component status.
22 Bring cables to the switch.
23 Install the first line card cable tray in the lowest slot.
24 Cable first line card.
25 Repeat Step23 for remaining line cards, working your way up.
26 Check link status.
24 Sun Datacenter Switch 3456 Installation Guide • December 2008
Cross-Reference
"Inspecting Pins" on page 48
"Repairing and Replacing Pins" on page
54
"To Install the Midplane Stiffener" on
page 63
Chapter 8
"To Remove the Midplane Stiffener" on
page 66
"Inspecting Pins" on page 48
"Repairing and Replacing Pins" on page
54
Chapter 9
"To Install the Line Card Filler Panels" on
page 41
"Installing Cable Guides" on page 93
"To Install Power Supplies" on page 83
"Preparing Power Supplies" on page 85
"Working With CMCs" on page 87
"Powering On the Sun Datacenter Switch
3456" on page 91
"To Install Cable Trays" on page 97
"Cabling the Switch" on page 98
"To Check Link Status" on page 103
