3. Starting on the front right corner of the chassis, lift the cable tree into position.
Have a helper assist in aligning the cable tree mounting screw holes with the
holes in the chassis.
4. While holding the cable tree in position, have a helper install the mounting
screws.
a. Using an Allen wrench, install the first M5x1.5 screw into the top hole on the
b. Install the second screw into the next lower hole.
c. Repeat from
5. Repeat
6. Press the cable tree into the switch chassis and firmly tighten all 22 screws from
top to bottom.
7. Repeat from

▼ To Remove Cable Trees

Note – Two people are required to remove the cable trees. One person must hold
the weight of the tree for an extended time.
1. Start on the front right corner of the Sun Datacenter Switch 3456 chassis.
a. Remove all screws from the front of the cable tree.
b. Remove all but the upper two screws from the right side of the cable tree.
c. While a helper lifts the weight of the cable tree, remove the two remaining
d. Lift the cable tree away from the chassis.
2. Repeat
96 Sun Datacenter Switch 3456 Installation Guide • December 2008
right side of the chassis.
Finger tighten the screw only.
Finger tighten the screw only.
Step a until all 11 screws are installed on the right side.
Step 4 for the 11 screws on the front of the right cable tree.
Step 3
for the other cable tree at the front left corner of the chassis.
screws from the right of the cable tree.
Step 1 for the cable tree on the front left corner of the switch chassis.
