Sun
StorEdge
FC-100 Hub
™
™
Installation and Service
Manual
Formerly the Sun
™
Enterprise Network Array
™
Sun Microsystems, Inc.
901 San Antonio Road
Palo Alto, CA 94303-4900 USA
650 960-1300
Fax 650 969-9131
Part No. 805-0315-12
September 1998, Revision A
Send comments about this document to: docfeedback@sun.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the STOREDGE FC-100 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Sun Microsystems STOREDGE FC-100

Summary of Contents for Sun Microsystems STOREDGE FC-100

  • Page 1 ™ Installation and Service Manual Formerly the Sun ™ Enterprise Network Array ™ Sun Microsystems, Inc. 901 San Antonio Road Palo Alto, CA 94303-4900 USA 650 960-1300 Fax 650 969-9131 Part No. 805-0315-12 September 1998, Revision A Send comments about this document to: docfeedback@sun.com...
  • Page 2 Sun, Sun Microsystems, the Sun logo, AnswerBook, Sun StorEdge, Sun Enterprise Network Array and Solaris are trademarks, registered trademarks, or service marks of Sun Microsystems, Inc. in the U.S. and other countries. All SPARC trademarks are used under license and are trademarks or registered trademarks of SPARC International, Inc.

  • Page 3: Regulatory Compliance Statements

    FCC radio frequency emission limits. Networking connections can be made using unshielded twisted-pair (UTP) cables. Modifications: Any modifications made to this device that are not approved by Sun Microsystems, Inc. may void the authority granted to the user by the FCC to operate this equipment.
  • Page 4 This Class B digital apparatus meets all requirements of the Canadian Interference-Causing Equipment Regulations. Cet appareil numérique de la classe B respecte toutes les exigences du Règlement sur le matériel brouilleur du Canada. Sun StorEdge FC-100 Hub Installation and Service Manual • September 1998...

  • Page 5: Safety Precautions

    Modifications to Equipment Do not make mechanical or electrical modifications to the equipment. Sun Microsystems is not responsible for regulatory compliance of a modified Sun product. Placement of a Sun Product Caution – Do not block or cover the openings of your Sun product.

  • Page 6: Einhaltung Sicherheitsbehördlicher Vorschriften

    Geräteschaden. Befolgen Sie die Anweisungen. Achtung – Hohe Temperatur. Nicht berühren, da Verletzungsgefahr durch heiße Oberfläche besteht. Sun StorEdge FC-100 Hub Installation and Service Manual • September 1998 Achtung – Gefährliche Spannungen. Anweisungen befolgen, um Stromschläge und Verletzungen zu vermeiden.
  • Page 7 Laser Klasse 1 Conformité aux normes de sécurité Ce texte traite des mesures de sécurité qu’il convient de prendre pour l’installation d’un produit Sun Microsystems. Mesures de sécurité Pour votre protection, veuillez prendre les précautions suivantes pendant l’installation du matériel : •...

  • Page 8: Normativas De Seguridad

    Pour écarter tout risque d’électrocution, branchez toujours ce cordon dans une prise mise à la terre. viii Sun StorEdge FC-100 Hub Installation and Service Manual • September 1998 L'avertissement suivant s'applique uniquement aux systèmes équipés d'un interrupteur VEILLEUSE: Attention : le commutateur d’alimentation de ce produit fonctionne comme un dispositif de mise en veille uniquement.
  • Page 9 En espera. Modificaciones en el equipo No realice modificaciones de tipo mecánico o eléctrico en el equipo. Sun Microsystems no se hace responsable del cumplimiento de las normativas de seguridad en los equipos Sun modificados.
  • Page 10 Los productos Sun que utilizan la tecnología de láser cumplen con los requisitos de láser de Clase 1. Class 1 Laser Product Luokan 1 Laserlaite Klasse 1 Laser Apparat Laser Klasse 1 GOST-R Certification Mark Sun StorEdge FC-100 Hub Installation and Service Manual • September 1998...

  • Page 11: Declaration Of Conformity

    Compliance ID: HUB 1063 Product Name: Sun StorEdge FC-100 Hub This product has been tested and complies with; European Union-EC This equipment complies with the following requirements of the EMC Directive 89/336/EEC EN55022 / CISPR22 (1985) EN50082-1 IEC801-2 (1991) IEC801-3 (1984)
  • Page 12 Sun StorEdge FC-100 Hub Installation and Service Manual • September 1998...

  • Page 13: Table Of Contents

    Contents Preface Product Description Sun StorEdge FC-100 Hub GBIC Installation Inspecting the Hub Rackmount Placement Installing the Hub 2.3.1 Tools You Will Need 2.3.2 Preparing the Cabinet 2.3.3 Installing the Mounting Tray in the Cabinet 2.3.4 Installing the Hub on the Mounting Tray 2.3.5...
  • Page 14 Installing a GBIC Removing a GBIC Removing a Hub A. Specifications Sun StorEdge FC-100 Hub Installation and Service Manual • September 1998...

  • Page 15: Preface

    Preface The Sun StorEdge FC-100 Hub Installation and Service Manual provides information on installing and servicing the Sun™ StorEdge™ FC-100 Hub. These instructions are designed for an experienced system administrator or trained service provider. Using UNIX Commands This document does not contain information on basic UNIX procedures such as shutting down the system, booting the system, and configuring devices.

  • Page 16: Typographic Conventions

    Shell C shell C shell superuser Bourne shell and Korn shell Bourne shell and Korn shell superuser Sun StorEdge FC-100 Hub Installation and Service Manual • September 1998 Meaning The names of commands, files, and directories; on-screen computer output What you type, when...

  • Page 17: Related Documentation

    Related Documentation Refer to the Sun StorEdge A5000 Disk Array Installation and Documentation Guide, part number 805-1903-xx, for a list of related documentation Sun Documentation on the Web The docs.sun.com web site enables you to access Sun technical documentation on the Web. You can browse the docs.sun.com archive or search for a specific book title or subject at: http://docs.sun.com Sun Welcomes Your Comments...
  • Page 18 Sun StorEdge FC-100 Hub Installation and Service Manual • September 1998...

  • Page 19: Product Description

    C H A P T E R Product Description This chapter describes the Sun StorEdge FC-100 Hub and Gigabit Interface Converters (GBICs). Sun StorEdge FC-100 Hub The hub is a seven-port connection point for Fibre Channel Arbitrated Loops (FC-ALs). Ports are connected using GBICs. Each port receives serial data from a remote node and retransmits that data out the next port to the next node in the loop.
  • Page 20 Front of Hub FIGURE 1-1 AC power Port 0 connector Rear of Hub FIGURE 1-2 Sun StorEdge FC-100 Hub Installation and Service Manual • September 1998 FIGURE 1-1 AC power LED Active LED (green) Bypass LED (yellow) Port 1 Port 2...

  • Page 21: Gbic

    GBIC The GBIC is compliant with Fibre Channel FC-PH-2 physical layer option 100-M5- SN-I and the ANSI FC-AL standard. The full speed of the module is 1062.5 Mbits/ second. The range of distances supported is 2 to 500 meters. Sun currently ships two types of GBICs: one with a bailed locking mechanism and one without.
  • Page 22 Sun StorEdge FC-100 Hub Installation and Service Manual • September 1998...

  • Page 23: Installation

    C H A P T E R Installation This chapter describes how to install the hub in a cabinet. Inspecting the Hub 1. Unpack the hub. 2. Inspect the hub for evidence of damage. If damaged, keep all contents and packing materials for the carrier’s agent to inspect.

  • Page 24: Installing The Hub

    Installing the Mounting Tray in the Cabinet 1. Select the correct mounting holes in the cabinet to use for the tray. Refer to the online Rackmount Placement Matrix for mounting hole information. Sun StorEdge FC-100 Hub Installation and Service Manual • September 1998...
  • Page 25 2. Install the tray in the cabinet ( Installing the Tray in the Cabinet FIGURE 2-1 Caution – Use only SAE 10-32 screws to secure the tray to the cabinet mounting rails. Using any other screw type will damage the cabinet mounting holes. a.

  • Page 26: Installing The Hub On The Mounting Tray

    Retaining tab Installing the Hub on a Mounting Tray FIGURE 2-2 Note – The front and rear mounting plastics are interchangeable. Sun StorEdge FC-100 Hub Installation and Service Manual • September 1998 FIGURE 2-2 Notch Position A Position B...

  • Page 27: Installing Gbics And Fiber Optic Cables

    2.3.5 Installing GBICs and Fiber Optic Cables 1. Choose the hub port into which you will install the GBIC. Although the ports in a hub are electrically equivalent, follow any configuration guidelines that may have accompanied the other hardware in your configuration. If you are connecting the GBIC to a Sun StorEdge A5000 Disk Array , refer to the Sun StorEdge A5000 Disk Array Hardware Configuration Guide, part number 805-0264-xx.

  • Page 28: Routing The Power Cord

    If you are installing the hub along with Sun StorEdge A5000 Disk Arrays in a Sun StorEdge Expansion Cabinet, refer to the Sun StorEdge A5000 Disk Array Hardware Configuration Guide, part number 805-0264-12 (or later), for cable routing. Sun StorEdge FC-100 Hub Installation and Service Manual • September 1998 FIGURE 2-3 FIGURE 2-4...

  • Page 29: Verifying The Configuration

    1. Connect the female end of the power cord to the power receptacle at the rear of the hub ( FIGURE 1-1 2. Route the power cord down the right side and along the bottom of the cabinet. 3. Route the power cord up through the cutout to the power distribution unit at the left side of the cabinet.

  • Page 30: Reassembling The Cabinet

    Module not properly inserted Diminished or missing signal from node Bad hub port Faulty GBIC Sun StorEdge FC-100 Hub Installation and Service Manual • September 1998 TABLE 2-1 Solution Remove and reinsert the GBIC. Plug the optical cable from the other device into a known good GBIC.

  • Page 31: Installing A Gbic

    C H A P T E R Service This chapter describes how to remove and install a GBIC. It also describes how to remove a hub. Installing a GBIC 1. Choose the hub port into which you will install the GBIC. Although the ports in a hub are electrically equivalent, follow any configuration guidelines that may have accompanied the other hardware in your configuration.
  • Page 32 To insert a GBIC that does not have a bail, slide the GBIC into the port until you hear a click. Installing a GBIC That Does Not Have a Bail FIGURE 3-1 Sun StorEdge FC-100 Hub Installation and Service Manual • September 1998...
  • Page 33 To insert a GBIC that has a bail, slide the GBIC into the available port with the bail in the unlocked (right) position. Once the GBIC is firmly seated in the port, move the bail left into the locked position. Slot Bail Installing a GBIC That Has a Bail...

  • Page 34: Removing A Gbic

    To remove a GBIC that does not have a bail, push the module tabs together and pull the GBIC out from the port. Removing a GBIC That Does Not Have a Bail FIGURE 3-3 Sun StorEdge FC-100 Hub Installation and Service Manual • September 1998 FIGURE 3-3 FIGURE 3-4...
  • Page 35 To remove a GBIC that has a bail, move the bail right to the unlocked position and pull on the plastic tab of the bail. Removing a GBIC That Has a Bail FIGURE 3-4 Chapter 3 Service...

  • Page 36: Removing A Hub

    FIGURE 3-5 Retaining tab Removing the Hub FIGURE 3-5 4. Pull the hub back and then lift it out of the mounting slots. Sun StorEdge FC-100 Hub Installation and Service Manual • September 1998 FIGURE 3-3 Position A Position B Notch...

  • Page 37: Specifications

    A P P E N D I X Specifications Physical Physical Specifications TABLE A-1 Height 1.69 in 42.92 mm Width Depth 8.6 in 14.35 in 218.4 mm 364.49 mm Weight 6 lbs 2.72 kg...
  • Page 38 TABLE A-3 Specification Temperature Vibration Shock Humidity Altitude Sun StorEdge FC-100 Hub Installation and Service Manual • September 1998 Value 95 to 120V 50 to 60 Hz 350 mA 1.0 A ( < 1 second) Operating Value 0C to 50C 1.25g, 5 to 500 Hz, sine...
