1. Locate the cable connector at iPASS connector 12B.
This cable is the upper cable.
2. Grasp the cable connector to support its weight and apply the removal force.
3. Pull on the loop of the retractor strap while simultaneously pulling on the
cable connector.
The cable connector comes free.
4. Carefully move the cable out of the front branch of the cable tree.
5. Gently lower the cable so that is it hanging from the side branch.
Caution – Do not allow the cable to drop or strike the floor. Jerking, bending,
pulling on, or dropping the cable will damage the cable. See
page 99.
6. Repeat from Step 1
This cable is the lower cable.
7. Repeat from Step 1
14B, and so on to 23A.
8. Repeat from Step 1
10B, and so on to 0A.

▼ To Check Link Status

1. Access the CMC as described in
for the cable at iPASS connector 12A.
moving to the right for cables at iPASS connectors 13B, 13A,
moving to the left for cables at iPASS connectors 11B, 11A,
"Working With CMCs" on page
"Cable Cautions" on
87.
Chapter 11 Cabling the Switch 103
