TABLE 2-3
configuration.
Suggested Configurations
TABLE 2-3
Quantity
Configuratio of Line
n Cards
Base 1
1/8 3
1/4 6
3/8 9
1/2 12
5/8 15
3/4 18
7/8 21
Because the line cards are equally distributed across the available slots, cabling rules
and lengths still apply. See
Switch 3456 Site Planning Guide.
10 Sun Datacenter Switch 3456 Installation Guide • December 2008
provides suggested configurations, based upon a fraction of the complete
Line Card Slots
11
11, 12, 10
11, 12, 10, 13, 9, 14
11, 12, 10, 13, 9, 14, 8, 15, 7
11, 12, 10, 13, 9, 14, 8, 15, 7, 16, 6, 17
11, 12, 10, 13, 9, 14, 8, 15, 7, 16, 6, 17, 5, 18, 4
11, 12, 10, 13, 9, 14, 8, 15, 7, 16, 6, 17, 5, 18, 4, 19,
3, 20
11, 12, 10, 13, 9, 14, 8, 15, 7, 16, 6, 17, 5, 18, 4, 19,
3, 20, 2, 21, 1
"Cabling the Switch" on page 98
Power Supply Slots
2, 4, 6, 9, 11, 13
2, 4, 6, 9, 11, 13, 0, 15
2, 4, 6, 9, 11, 13, 0, 15
2, 4, 6, 9, 11, 13, 0, 15, 7, 8
2, 4, 6, 9, 11, 13, 0, 15, 7, 8, 3, 12
2, 4, 6, 9, 11, 13, 0, 15, 7, 8, 3, 12
2, 4, 6, 9, 11, 13, 0, 15, 7, 8, 3, 12, 1, 14
2, 4, 6, 9, 11, 13, 0, 15, 7, 8, 3, 12, 1, 14,
5, 10
and the Sun Datacenter
