Chassis Activity Dimensions

provides Sun Datacenter Switch 3456 chassis dimensions, and the
TABLE 1-1
minimum dimensions needed for unpacking, moving, and the final location.
Approximate Minimum Chassis Activity Dimensions
TABLE 1-1
Item Length
Sun Datacenter 6 ft (1.8 m)
Switch 3456
chassis
Unpacking space 35 ft (10.7 m)
Moving perimeter 15 ft (4.6 m)
Installation at 12 ft (3.7 m)
final location
Final location 8 ft (2.4 m)

Heat Considerations

This section describes the heat output of the Sun Datacenter Switch 3456 and its
potential safety hazard for personnel. This section also describes keeping an open
area at the exhaust side, and considerations for other systems and equipment in the
area.

Air Temperature

The calculated approximate air temperature output of the Sun Datacenter Switch
3456 is 36°F (20°C) hotter than the air going in. While this output temperature is not
hot enough to burn, this temperature is sufficient to dehydrate and render useless
any cooling device in the vicinity.
Width Height
4 ft (1.2 m) 5 ft (1.5 m)
10 ft (3 m) 9 ft (2.7 m)
10 ft (3 m) 6 ft (1.8 m)
12 ft (3.7 m) 6 ft (1.8 m)
10 ft (3 m) 6 ft (1.8 m)
Chapter 1
Comment
Dimensions of chassis.
To accommodate rollout
and crate shell movement
For stopping distance and
safety margin.
To accommodate line card
and fabric card
installation.
Dimensions outside of
cable guides, access space
only.
Cautions and Considerations 3
