FIGURE 11-1
Note – The support rib for the plate is on the underside and visible from the front
of the switch chassis. From the back of the switch, the plates appear smooth.
b. Tighten the screws securely.
c. Repeat from
2. Repeat
▼ To Remove Cable Plates
1. Starting on the right side of the Sun Datacenter Switch 3456 chassis, remove the
cable plates.
a. Using an Allen wrench, remove the four M5 x 1.5 screws that secure the
b. Remove the cable plate from the chassis.
94
Sun Datacenter Switch 3456 Installation Guide • December 2008
Cable Plate Locations
Step a
for the next higher cable plate and continue until all six
cable plates are installed.
Step 1
for the left side of the switch.
upper cable plate.
