Feature
Pending operation
11.4.9

CPU Submenu

Feature
Processor Type
CPU Signature
Microcode Patch
FSB Speed
Max CPU Speed
Min CPU Speed
CPU Speed
Processor Cores
Intel HT Technology
Intel VT-x Technology
Intel SMX Technology
64-bit
EIST Technology
CPU C3 State
CPU C6 State
CPU C7 State
L1 Data Cache
L1 Code Cache
L2 Cache
L3 Cache
Set Boot Freq Ratio
Hyper-Threading
Active Processor Cores
Overclocking Lock
Copyright © 2013 congatec AG
Options Description
None, Perform selected TPM chip operation.
Enable Take Note: System might restart several times during POST to perform selected operation.
Ownership,
Disable Take
Ownership,
TPM Clear
Options Description
Displays the processor ID string. The "Processor Type" is not displayed, just the ID string.
no option
no option Displays the CPU Signature.
no option Displays the revision of the Microcode Patch.
no option Displays the FSB Speed.
no option Displays the Max CPU Speed.
no option Displays the Min CPU Speed.
no option Displays the current CPU Speed.
no option Displays the number of the Processor Cores.
no option Displays whether Intel HT Technology is supported.
no option Displays whether Intel VT-x Technology is supported.
no option Displays whether Intel SMX Technology is supported.
no option Displays whether 64-bit is supported.
no option Displays whether Enhanced Intel SpeedStep Technology (EIST) is supported.
no option Displays whether CPU C3 State is supported.
no option Displays whether CPU C6 State is supported.
no option Displays whether CPU C7 State is supported.
no option Displays the size of the L1 Data Cache.
no option Displays the size of the L1 Code Cache.
no option Displays the size of the L2 Cache.
no option Displays the size of the L3 Cache.
8-23 Range: 8 - 23. This sets the boot ratio. If ratio is out of range, maximum ratio is used. Non-ACPI OSes will use this
Default : 255 ratio.
The range 8-23 is just an example as the possible range depends on processor variant.
Disabled Enable or Disable Hyper-Threading technology.
Enabled
All Set number of cores to be enabled.
1
2
3
FLEX_RATIO(194) MSR
Disabled
Enabled
TU87m12 89/114
