8.4.17

SATA Submenu

Feature
SATA Controller(s)
SATA Mode Selection
CR#1 - RST Pcie Storage Remapping
CR#1 - Remap Port Selection
CR#2 - RST Pcie Storage Remapping
CR#2 - Remap Port Selection
CR#3 - RST Pcie Storage Remapping
CR#3 - Remap Port Selection
SATA Test Mode
Alternate ID
► Software Feature Mask Configuration
Aggressive LPM Support
Serial ATA Port 0, 1, 2
Software Preserve
Copyright © 2016 congatec AG
Options Description
Enabled Enable or disable the onboard SATA controller(s).
Disabled
AHCI
Select SATA controller mode.
RAID Note: RAID option is not supported on all chipsets.
Enabled Enable or disable RST PCIe storage remapping.
Disabled
Auto Select port for RST PCIe storage remapping,
Port 9
Port 10
Port 11
Port 12
Enabled Enable or disable RST Pcie storage remapping.
Disabled
Auto Select port for RST PCIe storage remapping,
Port 13
Port 14
Port 15
Port 16
Enable or disable RST PCIe storage remapping.
Enabled
Disabled
Auto Select port for RST PCIe storage remapping.
Port 17
Port 18
Port 19
Port 20
Enabled Only enable this feature for verification measurements.
Disabled
Enabled Enable this feature to report an alternate device ID.
Disabled Note: Displayed only for RAID SATA mode.
Submenu RAID option ROM and Intel
Mask Configuration' to enable or disable the storage features.
Enabled Enable PCH to aggressively enter link power state.
Disabled
No option Displays the name of the connected Hard Disk or DVDROM if the port is enabled. No options are
displayed if the port is disabled or when the port is enabled but no device is connected to it.
No option Indicates whether the detected drive supports software settings preservation.
® Rapid Storage Technology driver will refer to the 'Software Feature
