VLT AQUA Drive
Instruction Manual
Figure 5.50:
Step 5: By pressing the [Hand on] button, the LED above
the button should be lit and the motor may rotate.
Figure 5.51:
Step 6: The speed of the motor can be seen in the LCP. It
can be adjusted by pushing the up
buttons.
Figure 5.52:
Step 7: To move the cursor, use the left ◄ and right ► arrow
buttons. This enables speed changes by larger increments.
▲ ▼
and down arrow
®
MG.20.M5.22 - VLT is a registered Danfoss trademark
Figure 5.53:
Step 8: Press the [Off] button to stop the motor again.
Figure 5.54:
Step 9: Change two motor wires if the desired direction of
rotation is not achieved.
Remove line power from the adjustable frequency
drive before changing motor wires.
5 Electrical installation
5
5-27
