VLT AQUA Drive
Instruction Manual
Analog output:
Number of programmable analog outputs
Terminal number
Current range at analog output
Max. resistor load to common at analog output
Accuracy on analog output
Resolution on analog output
The analog output is galvanically isolated from the supply voltage (PELV) and other high-voltage terminals.
Control card, 24 V DC output:
Terminal number
Max. load
The 24 V DC supply is galvanically isolated from the supply voltage (PELV), but has the same potential as the analog and digital inputs and outputs.
Relay outputs:
Programmable relay outputs
Relay 01 Terminal number
1)
Max. terminal load (AC-1) on 1-3 (NC), 1-2 (NO) (Resistive load)
1)
Max. terminal load (AC-15) (Inductive load @ cosφ 0.4)
1)
Max. terminal load (DC-1) on 1-2 (NO), 1-3 (NC) (Resistive load)
1)
Max. terminal load (DC-13) (Inductive load)
Relay 02 Terminal number
Max. terminal load (AC-1) 1) on 4-5 (NO) (Resistive load)
Max. terminal load (AC-15) 1) on 4-5 (NO) (Inductive load @ cosφ 0.4)
1)
Max. terminal load (DC-1) on 4-5 (NO) (Resistive load)
1)
Max. terminal load (DC-13) on 4-5 (NO) (Inductive load)
1)
Max. terminal load (AC-1) on 4-6 (NC) (Resistive load)
1)
Max. terminal load (AC-15) on 4-6 (NC) (Inductive load @ cosφ 0.4)
Max. terminal load (DC-1) 1) on 4-6 (NC) (Resistive load)
Max. terminal load (DC-13) 1) on 4-6 (NC) (Inductive load)
Min. terminal load on 1-3 (NC), 1-2 (NO), 4-6 (NC), 4-5 (NO)
Environment according to EN 60664-1
1) IEC 60947 part 4 and 5
The relay contacts are galvanically isolated from the rest of the circuit by reinforced isolation (PELV).
2) Overvoltage Category II
3) UL applications 300 V AC 2A
Control card, 10 V DC output:
Terminal number
Output voltage
Max. load
The 10 V DC supply is galvanically isolated from the supply voltage (PELV) and other high-voltage terminals.
2)3)
®
MG.20.M5.22 - VLT is a registered Danfoss trademark
10 Specifications
0/4–20 mA
Max. error: 0.8% of full scale
: 200 mA
1-3 (break), 1-2 (make)
240 V AC, 2 A
240 V AC, 0.2 A
60 V DC, 1A
24 V DC, 0.1A
4-6 (break), 4-5 (make)
400 V AC, 2 A
240 V AC, 0.2 A
80 V DC, 2 A
24 V DC, 0.1A
240 V AC, 2 A
240 V AC, 0.2 A
50 V DC, 2 A
24 V DC, 0.1 A
24 V DC 10 mA, 24 V AC 20 mA
overvoltage category III/pollution degree 2
10.5 V ±0.5 V
1
42
500 Ω
8 bit
12, 13
2
10
50
25 mA
10-13
