VLT AQUA Drive
Instruction Manual
[1654] Feedback 1 [Unit]
[1655] Feedback 2 [Unit]
[1656] Feedback 3 [Unit]
[1660] Digital Input
[1661] Terminal 53 Switch Setting
[1662] Analog Input 53
[1663] Terminal 54 Switch Setting
[1664] Analog Input 54
[1665] Analog Output 42 [mA]
[1666] Digital Output [bin]
[1667] Freq. Input #29 [Hz]
[1668] Freq. Input #33 [Hz]
[1669] Pulse Output #27 [Hz]
[1670] Pulse Output #29 [Hz]
[1671] Relay Output [bin]
[1672] Counter A
[1673] Counter B
[1675] Analog input X30/11
[1676] Analog input X30/12
[1677] Analog output X30/8 [mA]
[1680] Serial com. bus CTW 1
[1682] Serial com. bus REF 1
[1684] Comm. Option STW
[1685] FC Port CTW 1
[1686] FC Port REF 1
[1690] Alarm Word
[1691] Alarm Word 2
[1692] Warning Word
[1693] Warning Word 2
[1694] Ext. Status Word
[1695] Ext. Status Word 2
[1696] Maintenance Word
[1830] Analog Input X42/1
[1831] Analog Input X42/3
[1832] Analog Input X42/5
[1833] Analog Out X42/7 [V]
[1834] Analog Out X42/9 [V]
[1835] Analog Out X42/11 [V]
[2117] Ext. 1 Reference [Unit]
View the value of Feedback 1. See also par. 20-0*.
View the value of Feedback 2. See also par. 20-0*.
View the value of Feedback 3. See also par. 20-0*.
Displays the status of the 6 digital input terminals (18, 19, 27, 29, 32 and 33). Input 18 corresponds
to the bit at the far left. Signal low = 0; Signal high = 1
Setting of input terminal 53. Current = 0; Voltage = 1.
Actual value at input 53 either as a reference or protection value.
Setting of input terminal 54. Current = 0; Voltage = 1.
Actual value at input 54 either as reference or protection value.
Actual value at output 42 in mA. Use par. 6-50 to select the variable to be represented by output
42.
Binary value of all digital outputs.
Actual value of the frequency applied at terminal 29 as a pulse input.
Actual value of the frequency applied at terminal 33 as a pulse input.
Actual value of pulses applied to terminal 27 in digital output mode.
Actual value of pulses applied to terminal 29 in digital output mode.
View the setting of all relays.
View the present value of Counter A.
View the present value of Counter B.
Actual value of the signal on input X30/11 (General Purpose I/O Card. Option)
Actual value of the signal on input X30/12 (General Purpose I/O Card. Optional)
Actual value at output X30/8 (General Purpose I/O Card. Optional) Use Par. 6-60 to select the var-
iable to be shown.
Control word (CTW) received from the bus master.
Main reference value sent with control word via the serial communications network, such as from
the BMS, PLC or another master controller, for example.
Extended serial communication bus option status word.
Control word (CTW) received from the bus master.
Status word (STW) sent to the bus master.
One or more alarms in a Hex code (used for serial communications).
One or more alarms in a Hex code (used for serial communications).
One or more warnings in a Hex code (used for serial communications).
One or more warnings in a Hex code (used for serial communications).
One or more status conditions in a Hex code (used for serial communications).
One or more status conditions in a Hex code (used for serial communications).
The bits reflect the status for the programmed preventive maintenance events in parameter group
23-1*.
Shows the value of the signal applied to terminal X42/1 on the analog I/O card.
Shows the value of the signal applied to terminal X42/3 on the analog I/O card.
Shows the value of the signal applied to terminal X42/5 on the analog I/O card.
Shows the value of the signal applied to terminal X42/7 on the analog I/O card.
Shows the value of the signal applied to terminal X42/9 on the analog I/O card.
Shows the value of the signal applied to terminal X42/11 on the analog I/O card.
The value of the reference for extended closed-loop controller 1.
®
MG.20.M5.22 - VLT is a registered Danfoss trademark
8 How to program the adjustable frequency
drive
8
8-11
