VLT AQUA Drive
Instruction Manual

4 Mechanical installation

4.1 Before starting

4.1.1 Checklist
When unpacking the adjustable frequency drive, make sure that the unit is undamaged and complete. Use the following table to identify the packaging:
Enclosure A2
type: (IP 20/ 21) (IP 20/21)
Unit size (kW):
200–240 V 0.25–3.0
380–480 V 0.37–4.0 5.5–7.5
525–600 V 0.75–7.5
Table 4.1: Unpacking table
Please note that a selection of screwdrivers (Philips or cross-thread screwdriver and torx), a side-cutter, drill and knife is also recommended to have
handy for unpacking and mounting the adjustable frequency drive. The packaging for these enclosures contains, as shown: accessory bag(s), documen-
tation and the unit. Depending on options fitted, there may be one or two bags and one or more booklets.
A3 A5 B1/B3
(IP 55/ 66) (IP20/ 21/ 55/ 66)
5.5–11/
3.7 0.25–3.7
5.5–11
11–18.5/
0.37–7.5
11–18.5
11–18.5/
0.75–7.5
11–18.5
®
MG.20.M5.22 - VLT is a registered Danfoss trademark
B2/B4 C1/C3
(IP20/ 21/ 55/66) (IP20/21/ 55/66)
15/ 18.5–30/
15–18.5 22–30
22-30/ 37-55/
22-37 45-55
22-37/ 45-55/
22-37 45-55
4 Mechanical installation
C2/C4
4
(IP20/21/ 55/66)
37-45/
37-45
75 - 90/
75-90
75 - 90/
75-90
4-1
