VLT AQUA Drive
Instruction Manual
6-50 Terminal 42 Output
Option:
[0] * No operation
[100] Output frequency
[101] Reference
[102] Feedback
[103] Motor current
[104] Torque rel to limit
[105] Torq relate to rated
[106] Power
[107] Speed
[113]

Ext. Closed-loop 1

[114] Ext. Closed-loop 2
[115] Ext. Closed-loop 3
[130] Output freq. 4-20mA
[131] Reference 4-20mA
[132] Feedback 4-20mA
[133] Motor cur. 4-20mA
[134] Torq.% lim 4-20 mA
[135] Torq.% nom 4-20 mA
[136] Power 4-20mA
[137] Speed 4-20mA
[139] Bus ctrl.
[140] Bus ctrl. 4-20 mA
[141] Bus ctrl t.o.
[142] Bus ctrl 4-20mA t.o.
[143] Ext. Closed-loop 1 4-20 mA
[144] Ext. Closed-loop 2 4-20 mA
[145] Ext. Closed-loop 3 4-20 mA
NOTE!
Values for setting the Minimum Reference is found in par.3-02
Maximum Reference
Reference is found in par.3-03
Function:
Select the function of terminal 42 as an analog current output.
0–100 Hz
Minimum reference - Maximum reference
-200% to +200% of par. 2-14
: 0 - Inverter Max. Current (par. 16-37)
: 0 - Torque limit (par. 4-16 Torque Limit Motor Mode
: 0 - Motor rated torque
0 - Motor rated power
Motor Speed High Limit [RPM]
0 - Speed High Limit (par.4-13
[Hz] )
0 - 100%
0 - 100%
0 - 100%
:0–100 Hz
Minimum Reference - Maximum Reference
-200% to +200% of par. 2-14
0 - Inverter Max. Current (par. 16-37
:0 - Torque limit (par. 4-16 Torque Limit Motor Mode
:0 - Motor rated torque
0 - Motor rated power
0 - Speed High Limit (par. 4-13 and par. 4-14)
0 - 100%
0 - 100%
0 - 100%
0 - 100%
0 - 100%
0 - 100%
0 - 100%
Minimum Reference
and par. 20-13
Maximum Reference/Feedb.
and par. 20-14
®
MG.20.M5.22 - VLT is a registered Danfoss trademark
8 How to program the adjustable frequency
)
and par. 4-14
Inv. Max. Current
)
)
Minimum Reference/Feedb.
.
drive
Motor Speed High Limit
8
- values for Maximum
8-31
