8 How to program the adjustable frequency
drive
6-14 Terminal 53 Low Ref./Feedb. Value
Range:
0.000 N/A* [-999999.999 - 999999.999 N/A]
6-15 Terminal 53 High Ref./Feedb. Value
Range:
50.000 N/ [-999999.999 - 999999.999 N/A]
A*
6-20 Terminal 54 Low Voltage
Range:
0.07 V* [0.00 - par. 6-21 V]
6-21 Terminal 54 High Voltage
Range:
10.00 V* [par. 6-20 - 10.00 V]
6-24 Terminal 54 Low Ref./Feedb. Value
8
Range:
0.000 N/A* [-999999.999 - 999999.999 N/A]
6-25 Terminal 54 High Ref./Feedb. Value
Range:
100.000 N/ [-999999.999 - 999999.999 N/A]
A*
8-30
Function:
Enter the analog input scaling value that corresponds to the low voltage/low current set in par.
6-10 Terminal 53 Low Voltage and par. 6-12
Function:
Enter the analog input scaling value that corresponds to the high voltage/high current value set in
par.6-11 Terminal 53 High Voltage and par. 6-13
Function:
Enter the low voltage value. This analog input scaling value should correspond to the low reference/
Terminal 54 Low Ref./Feedb. Value
feedback value, set in par.6-24
Function:
Enter the high voltage value. This analog input scaling value should correspond to the high refer-
ence/feedback value set in par.6-25
Function:
Enter the analog input scaling value that corresponds to the low voltage/low current value set in
Terminal 54 Low Voltage
par.6-20 and par. 6-22
Function:
Enter the analog input scaling value that corresponds to the high voltage/high current value set in
par.6-21 Terminal 54 High Voltage and par. 6-23
®
