8 How to program the adjustable frequency
drive
[191] Dry Pump
[192] End of Curve
[193] Sleep Mode
[194] Broken Belt
[195] Bypass Valve Control
[199] Pipe Filling
[211] Cascade Pump1
[212] Cascade Pump2
[213] Cascade Pump3
[223] Alarm, Trip-locked
[224] Bypass Mode Active
5-53 Term. 29 High Ref./Feedb. Value
Range:
100.000 N/ [-999999.999 - 999999.999 N/A]
A*

8.2.8 6-** Analog In/Out

8
Parameter group for configuring the analog input and output.
6-00 Live Zero Timeout Time
Range:
10 s* [1 - 99 s]
8-28
Function:
Enter the high reference value [RPM] for the motor shaft speed and the high feedback value, see
Term. 33 High Ref./Feedb. Value
also par. 5-58
Function:
Enter the Live Zero Timeout time period. Live Zero Timeout Time is active for analog inputs, (i.e.,
terminal 53 or terminal 54), allocated to current and used as reference or feedback sources. If the
reference signal value associated with the selected current input falls below 50% of the value set
Terminal 53 Low Voltage
in par.6-10 , par. 6-12
Voltage Terminal 54 Low Current
or par. 6-22
Live Zero Timeout Time
6-00 , the function selected in par.6-01
activated.
®
MG.20.M5.22 - VLT is a registered Danfoss trademark
.
Terminal 53 Low Current Terminal 54 Low
, par.6-20
for a time period longer than the time set in par.
Live Zero Timeout Function
®
VLT AQUA Drive
Instruction Manual
will be
