VLT AQUA Drive
Instruction Manual
6-01 Live Zero Timeout Function
Option:
[0] * Off
[1] Freeze output
[2] Stop
[3] Jogging
[4] Max. speed
[5] Stop and trip
6-10 Terminal 53 Low Voltage
Range:
0.07 V* [0.00 - par. 6-11 V]
6-11 Terminal 53 High Voltage
Range:
10.00 V* [par. 6-10 - 10.00 V]
Function:
Select the timeout function. The function set in par.6-01
if the input signal on terminal 53 or 54 is below 50% of the value in par.6-10
Voltage Terminal 53 Low Current
, par. 6-12
54 Low Current
for a time period defined in par.6-00
occur simultaneously, the adjustable frequency drive prioritizes the timeout functions as follows:
Live Zero Timeout Function
1. par.6-01
2. par. 8-04 Control Timeout Function
The output frequency of the adjustable frequency drive can be:
• [1] frozen at the present value
• [2] overruled to stop
• [3] overruled to jog speed
• [4] overruled to max. speed
• [5] overruled to stop with subsequent trip
If you select set-up 1-4, par. 0-10
This parameter cannot be adjusted while the motor is running.
Function:
Enter the low voltage value. This analog input scaling value should correspond to the low reference/
Terminal 53 Low Ref./Feedb. Value
feedback value set in par.6-14
Function:
Enter the high voltage value. This analog input scaling value should correspond to the high refer-
ence/feedback value set in par.6-15
®
MG.20.M5.22 - VLT is a registered Danfoss trademark
8 How to program the adjustable frequency
Live Zero Timeout Function
Terminal 54 Low Voltage
, par.6-20
Live Zero Timeout Time
Active Set-up Multi Set-up
must be set to
.
Terminal 53 High Ref./Feedb. Value
drive
will be activated
Terminal 53 Low
Terminal
or par. 6-22
. If several timeouts
, [9].
8
.
8-29
