The Function Set-up parameters are grouped in the following way:
Q3-10 Clock Settings
0-70 Set Date and Time
0-71 Date Format
0-72 Time Format
0-74 DST/Summertime
0-76 DST/Summertime Start
0-77 DST/Summertime End
Q3-20 Digital Reference
3-02 Minimum Reference
3-03 Maximum Reference
3-10 Preset Reference
5-13 Terminal 29 Digital Input
5-14 Terminal 32 Digital Input
5-15 Terminal 33 Digital Input
Q3-30 Feedback Settings
1-00 Configuration Mode
20-12 Reference/Feedb.Unit
3-02 Minimum Reference
3-03 Maximum Reference
6-20 Terminal 54 Low Voltage
6-21 Terminal 54 High Voltage
6-24 Terminal 54 Low Ref/Feedb Value
6-25 Terminal 54 High Ref/Feedb Value
6-00 Live Zero Timeout Time
6-01 Live Zero Timeout Function
Q3-1 General Settings
Q3-11 Display Settings
0-20 Display Line 1.1 Small
0-21 Display Line 1.2 Small
0-22 Display Line 1.3 Small
0-23 Display Line 2 Large
0-24 Display Line 3 Large
0-37 Display Text 1
0-38 Display Text 2
0-39 Display Text 3
Q3-2 Open-loop Settings
Q3-3 Closed-loop Settings
Q3-31 PID Settings
20-81 PID Normal/Inverse Control
20-82 PID Start Speed [RPM]
20-21 Setpoint 1
20-93 PID Proportional Gain
20-94 PID Integral Time
®
MG.20.M5.22 - VLT is a registered Danfoss trademark
8 How to program the adjustable frequency
Q3-12 Analog Output
6-50 Terminal 42 Output
6-51 Terminal 42 Output Min Scale
6-52 Terminal 42 Output Max Scale
Q3-21 Analog Reference
3-02 Minimum Reference
3-03 Maximum Reference
6-10 Terminal 53 Low Voltage
6-11 Terminal 53 High Voltage
6-14 Terminal 53 Low Ref/Feedb. Value
6-15 Terminal 53 High Ref/Feedb. Value
drive
Q3-13 Relays
Relay 1 ⇒ 5-40 Function Relay
Relay 2 ⇒ 5-40 Function Relay
Option relay 7 ⇒ 5-40 Function
Relay
Option relay 8 ⇒ 5-40 Function
Relay
Option relay 9 ⇒ 5-40 Function
Relay
8
8-5
