780C Multi-Interface Interoperability Tester – User Guide
The Audio Pattern (Test Tone) menu appears as shown below:
3. Touch select the desired Interface from the Audio Pattern (Test Tone) menu (refer to the screen shot
above which shows HDMI). The options are Optical, SPDIF or HDMI.
4. Double touch select the Dolby Digital Plus 7.1/TrueHD or DTS-HD item on the Audio Pattern (Test
Tone) menu (refer to the screen shot above).
One of the following screens will appear:
