780C Multi-Interface Interoperability Tester – User Guide
2. Touch select the desired test pattern from the menu shown below. You can select patterns that are
standard with the 780C or bitmaps that you have imported.
Note: A "+" on the lower right portion of the pattern indicates that there are options related to the specific
pattern. In these cases you double touch select to access the lower level menu.
3. (If applicable) Specify the test pattern options. Use the information in Table 4-3 below as a guide.
Note: There may be additional patterns not shown in the table.
Table 4-3: Test Patterns
Pattern Name
