780C Multi-Interface Interoperability Tester – User Guide
Table 4-3: Test Patterns
Pattern Name
White Pluge Pattern
Application: To set the contrast
and brightness controls on
fixed pixel displays.
September 29, 2014
Variant
No Variants
Options
Pixel values in RGB, 10bit
with limited range (TV)
mode.
Pixel values in RGB, 12bit
with limited range (TV)
mode.
Pixel values in RGB, 8bit
with limited range (TV)
mode.
Range of Values
Outer background:
R=64 G=64 B=64
Outer blinking box:
R=80/64 G=80/64 B=80/64
Inner blinking box:
R=36/64 G=36/64 B=36/64
Top most stair value:
R=940 G=940 B=940
Second stair value:
R=720 G=720 B=720
Third stair value:
R=560 G=560 B=560
Fourth stair value:
R=448 G=448 B=448
Bottom stair value:
R=360 G=360 B=360
Outer background:
R=256 G=256 B=256
Outer blinking box:
R=320/256 G=320/256 B=320/256
Inner blinking box:
R=144/256 G=144/256 B=144/256
Top most stair value:
R=3760 G=3760 B=3760
Second stair value:
R=2880 G=2880 B=2880
Third stair value:
R=2240 G=2240 B=2240
Fourth stair value:
R=1792 G=1792 B=1792
Bottom stair value:
R=1440 G=1440 B=1440
Top background:
R=16 G=16 B=16
Top dark vertical line:
R=8 G=8 B=8
Top larger (outer) box:
R=18 G=18 B=18
Top smaller (inner) box:
R=20 G=20 B=20
Bottom background:
R=235 G=235 B=235
Bottom larger (outer) box:
R=232 G=232 B=232
Bottom smaller (inner) box:
R=230 G=230 B=230
