Table 12-6 below lists the format names, their resolutions and frame rates for television formats. For command
line control you would use the format name as the argument for the FMTL command.
Table 12-6: List of HDTV Format Names for Command Line
Applies to: HDMI, DVI (TV), Analog YPbPr Video Signal Types
Syntax for Format Name
480i[frame rate] e.g.: 480i29
480p[frameRate] e.g.: 480p59
576i[frame rate] e.g.: 576i25
576p[frameRate] e.g.: 576p50
720p[frameRate] e.g.: 720p25
1080i[frameRate] e.g.: 1080i25
1080p[frameRate] e.g.: 1080p30
September 29, 2014
Resolution Frame Rates (Hz)
H: 720; V: 480 29.97, 30, 59.94, 60, 119.88, 120
H: 720; V: 480 59.94, 60, 119.88, 120
H: 720; V: 576 25, 50, 100
H: 720; V: 576 50, 100
H: 1280; V: 720 24, 25, 29.97, 30, 59.94, 60, 100,
119.88, 120
H: 1920; V: 1080 25, 29.97, 30, 50, 59.94, 60
H: 1920; V: 1080 25, 29.97, 30, 50, 59.94, 60
Page 225
Command example
FMTL 480i60
FMTU
FMTL 480p60
FMTU
FMTL 576i25
FMTL
FMTL 576p50
FMTU
FMTL 720p60
FMTU
FMTL 1080i59
FMTU
FMTL 1080p60
FMTU
