Table 6-2: Format Analyzer - SDI
Timing Parameters (left side)
Total
Active
Frames/sec
Scan Type
Video Parameters
(right side)
SMPTE embedded Stream 1
Description
Picture Rate
Sampling Structure
Bit Depth
SMPTE embedded packet Stream 2
6.2

Viewing Source Data Island Packets on HDMI and HDBaseT

This subsection describes how to view the HDMI/HDBaseT data island packets from an HDMI source device or
HDBaseT output of a repeater or distribution device.
6.2.1

Configurations for Viewing the Data Island Packets from an HDMI or HDBaseT Source Device

The 780C's HDMI/HDBaseT input ports acts as "reference" HDMI sink devices. Therefore they enable you to
emulate a known good HDMI sink device to conduct a test on a source device. You can view the data island
packets with the source device connected directly to the 780C. This test configuration is shown below for HDMI
and HDBaseT (second illustration).
September 29, 2014
Description
Total horizontal and vertical resolution including blanking.
Total active horizontal and vertical resolution excluding blanking.
The frame rate of the HDMI/DVI input source.
Indicates whether the HDMI/DVI input source is progressive or interlaced.
Description
Total active lines. E.g. 720.
Frames per second: E.g. 60
Video Type and Sampling: YCbCr 4:2:2
Scan: Progressive or Interlaced
Color depth plus overhead: 10 bits
Alignment level
Page 104
