780C Multi-Interface Interoperability Tester – User Guide
Table 12-7 lists some of the format names for computer formats. For command line control you would use the
format name as the argument for the FMTL command as shown in the example
Note: The following table only shows a sample of some of the more common formats. The other names
can be obtained from the list on the 780C itself.
Table 12-7: Partial List of Computer Format Names for Command Line
Applies to: DVI (Computer) Analog RGB Video Signal Types
Format Name
640x480_72Hz
800x600_56Hz
1024x768_60Hz
1280x768_60Hz
1280x1024_60Hz
1600x1024_60Hz
1920x1440_60Hz
Table 12-8 below lists the image names. For command line control you would use the image name as the
argument for the IMGU command.
Table 12-8: List of Image parameter names for command line
Image Name Example
SMPTEBar
IMGL SMPTEBar
IMGU
H_Stair IMGL H_Stair
(Horizontal) IMGU
Pluge IMGL Pluge
IMGU
Needle IMGL Needle
IMGU
HiLoTrk IMGL HiLoTrk
(White Pluge) IMGU
Overscan IMGL Overscan
IMGU
Window1 IMGL Window1
(30 IRE) IMGU
Window2 IMGL Window2
(80 IRE) IMGU
September 29, 2014
Command example
FMTL 640x480_72Hz
FMTU
FMTL 800x600_56Hz
FMTU
FMTL 1024x768_60Hz
FMTU
FMTL 1280x768_60Hz
FMTU
FMTL 1280x1024_60Hz
FMTU
FMTL 1600x1024_60Hz
FMTU
FMTL 1920x1440_60Hz
FMTU
Image Name Example
Regulate
IMGL Regulate
IMGU
Checker IMGL Checker
(6x6) IMGU
Focus IMGL Focus
IMGU
Multibrst IMGL Multibrst
IMGU
SplitGray IMGL SplitGray
(11 vertical bars) IMGU
LG_V_CBAR IMGL LG_V_CBAR
(Vertical bars) IMGU
LG_H_CBAR IMGL LG_H_CBAR
(Horiz bars) IMGU
V_3BARS IMGL V_3BARS
(UL 3 bar pattern) IMGU
Image Name Example
Flat_Yel
IMGL Flat_Yel
IMGU
Flat_Blk IMGL Flat_Blk
IMGU
Crosshtch (Grid) IMGL Crosshtch
IMGU
Anmorphic IMGL Anmorphic
IMGU
GrayBar IMGL GrayBar
IMGU
Staircase IMGL Staircase
IMGU
PulseBar IMGL PulseBar
IMGU
Rev_Grid IMGL Rev_Grid
IMGU
