Specifications
Item
Programming Console function
Device Monitor function
Mathematical function
Transmission System program
functions transmission
Screen data
transmission
History data
uploading

Communications Specifications

For a Host Link, RS-232C
Item
Communications standard
Communications settings
Connector
Number of Units connected
Transmission distance
Communications protocol
* When using an NT-AL001, the specifications are as follows.
• RS-232C cable:
• RS-422A cable:
250
Executes functions equivalent to those of a C200H-PRO27-E Programming Console
for CPM1, CPM1A, CPM2A, CPM2C, CQM1 (-EV1 only), CQM1H, C200HX/HG/
HE(-Z)E, and SRM1 (C02-V2 only) PLCs.
Executes functions as a Programming Console for CS/CJ-series PLC.
The Device Monitor function can be used to change the PLC's operating mode, read/
change words in the PLC's data areas, and display the PLC's error log. Compatible
PLCs include the CPM1, CPM1A, CPM2A, CPM2C, CQM1, CQM1H, C200HX/HG/
HE(-Z)E, SRM1, and CS/CJ-series PLCs.
Up to 256 calculation expressions can be registered along with the screen data. The
mathematical function reads the required data from numeral memory tables or host
words, executes the registered calculations, and writes the results.
Arithmetic operators, logic operators, bit operators, and comparative operators can be
used.
Downloads the system program from the system installer
Downloads/Upload the system program with a Memory Unit.
- Function for downloading screen data to and uploading screen data from the
Support Tool
- Function for transmitting screen data to and from the Memory Unit.
Function for uploading display/alarm history data from PT.
EIA RS-232C
Start-stop synchronization
Communications speed:
Data length:
Stop bit:
Parity:
9-pin D-SUB connector (female) (serial port A, B)
1:1
Max. 15 m*
C-series SYSWAY (1:N)
Max. 2 m
Total length 500 m max.
Specifications
Specification
9600, 19200 bps
7 bits
2 bits
Even
Appendix A
