Connecting to the Host's RS-232C Port
Note
Name Model
Connector XM2S-0911
hood
XM2S-0913
XM2S-0911-E
XM2S-2511
DB-C2-J9
Cable AWG28×5P
IFVV-SB
CO-MA-VV-SB
5P×28AWG
Cables with Connectors Made by OMRON
When connecting an NT-AL001 and a PLC, use the OMRON cables with con-
nectors indicated in the table below.
Model Cable Length
XW2Z-070T-1 0.7 m
XW2Z-200T-1 2 m
1. The maximum tensile load of the recommended cable is 30 N. Do not ex-
ceed this load.
2. After connecting a connecting cable, always tighten the connector screws.
Recommended Connectors, Cables and Crimp Terminals for RS-422A/
485
When making an RS-422A/485 connecting cable, as far as possible use the
recommended parts indicated in the table below. Some Units come supplied
with one connector and connector hood.
Check the required parts and prepare them in advance.
Name Model
Connector XM2A-2501
DB-25P F-N
Connector XM2S-2511
hood
DB-C2-J9
Remarks
9-pin type C-series CQM1, C200HS,
C200HX/HG/HE(-Z)E
Made by OMRON
CVM1/CV-series CPU Units
CV500-LK201
Made by OMRON 9-pin
Made by OMRON 9-pin CS/CJ-series CPU Units
25-pin type C500-LK203
Made by OMRON 3G2A5-LK201-EV1
C200H-LK201-V1
25-pin type 3G2A5-LK201-EV1
Made by JAE 3G2A6-LK201-EV1
Multi-core shielded
cable
Made by Fujikura, Ltd.
Multi-core shielded
cable
Made by Hitachi, Ltd.
Connector Specification
9-pin ⇔ 9-pin
Host link, NT Link (1:1), NT Link (1:N)
+5 V power supplied from PLC
(Use when the PLC has a +5 V output.)
Maker
25-pin type Delivered with the following
Units:
Made by OMRON
C500-LK203
25-pin type Delivered with the following
Units:
Made by JAE
3G2A6-LK201-EV1
3G2A5-LK201-EV1
25-pin type Delivered with the following
Units:
Made by OMRON
C500-LK203
25-pin type Delivered with the following
Units:
Made by JAE
3G2A6-LK201-EV1
3G2A5-LK201-EV1
Section 5-1
Delivered with
Remarks
