Setting the Bar Code Reader Input Function
186
• Pressing Abort on the communications condition/confirmation method
setting screen causes the NT631/NT631C to return to the memory switch
setting screen (4/4) without executing setting (with the previous settings
still effective).
On completion of communications condition/confirmation method setting, the
NT631/NT631C returns to the memory switch setting screen (4/4).
To set other memory switches, select the relevant screen using the [ ] (next
screen) or [ ] (previous screen) touch switch, then make the setting.
• To confirm the settings and quit the memory switch setting screen, press
the Quit touch switch. The settings made last will be set and the NT631/
NT631C will return to the MAINTENANCE MODE MENU screen.
• To quit the memory switch setting screen without confirming the settings,
press the Abort touch switch. The NT631/NT631C will return to the MAIN-
TENANCE MODE MENU screen with the previous settings still in effect.
Press the Set touch switch to the right of
Comm. A Method.
Display the required setting for each item
by pressing the touch switches.
The setting option changes each time the
touch switch is pressed.
Press Quit.
Section 6-10
