Compatible Systems; Connection Method - Omron Programmable Terminals NT631 Setup Manual

Device Monitor Function

6-13-1 Compatible Systems

6-13-2 Connection Method

CQM1H or C200HX/HG/
HE(-Z)E
CQM1 or C200HS
The following table shows the combinations of communications methods and
PLCs that can support the PT's Device Monitor function.
Communications
method
1:1 NT Link C200HS-CPU21/23/31/33
C200HE-CPU32/42 (-Z)E
C200HG-CPU33/43/53/63 (-Z)E
C200HX-CPU34/44/54/64 (-Z)E
C200HX-CPU65-ZE
C200HX-CPU85-ZE
CPM1-10CDR-@
CPM1-20CDR-@
CPM1A-10CD@-@
CPM1A-20CD@-@
CPM1A-30CD@-@
CPM1A-40CD@-@
CPM2A-30CD@@-@
CPM2A-40CD@@-@
CPM2A-60CD@@-@
CPM2C-10@@@@@@-@
CPM2C-20@@@@@@-@
CQM1-CPU4@-EV1
CQM1H-CPU21/51/61
SRM1-C02-V2
1:N NT Link C200HE-CPU32/42 (-Z)E
C200HG-CPU33/43/53/63 (-Z)E
C200HX-CPU34/44/54/64 (-Z)E
C200HX-CPU65-ZE
C200HX-CPU85-ZE
CQM1H-CPU21/51/61
SRM1-C02-V2
CS1G-CPU42/43/44/45-E(V1)
CS1H-CPU63/64/65/66/67-E(V1)
CS1G-CPU42H/43H/44H/45H
CS1H-CPU63H/64H/65H/66H/67H
CS1D-CPU65H/67H
CJ1G-CPU44/45
CJ1G-CPU42H/43H/44H/45H
CJ1H-CPU65H/66H/67H
CJ1M-CPU11/12/13/21/22/23
*1
A CPM1-CIF01 RS-232C Adapter is required.
*2
Use a Conversion Cable (CPM2C-CN111 or CS1W-CN114/118), CPM1-
CIF01 RS-232C Adapter, or CPM1-CIF11 RS-422A Adapter to connect to
the PLC.
The 1:1 NT Link or 1:N NT Link can be used. The connection method is
exactly the same as for the 1:1 NT Link or 1:N NT Link. Refer to SECTION 4
Connecting to the Host from the RS-232C Port or SECTION 5 Connecting to
the Host from the RS-422A/485 Port for details on connecting to the PLC.
The 1:1 NT Link can be used. The connection method is exactly the same as
for the 1:1 NT Link. Refer to SECTION 4 Connecting to the Host from the RS-
232C Port or SECTION 5 Connecting to the Host from the RS-422A/485 Port
for details on connecting to the PLC.
PLC model
*1
*1
*1
*1
*1
*1
*2
*2
