System Maintenance

6-11-6 Checking Screen Data

Reference:
198
Example Print-out
All of the recorded data is printed out in the same order as on the currently
displayed screen.
Example:
Sort by occurrence method, from oldest record
No. Comment
1 Remote I/O Error
2 PIC Unit Error
3 Cycle Time Over
The NT631/NT631C allows the registered screens (Nos. 1 to 3999) to be dis-
played and checked by operation from the System Menu.
• Window screens cannot be displayed by operation from the System
Menu.
• Only the user screens (Nos. 1 to 3999) can be displayed. Screens for sys-
tem use cannot be displayed.
If necessary, select the next or previous
screen by pressing [↓] (next screen) or
[↑] (previous screen).
The example screen to the left shows a
display for the sort by occurrence
method (from oldest record).
If required, press Prt. to print the display
history record data.
Press Quit.
The NT631/NT631C returns to the
ALARM HISTORY MENU screen.
YY/MM/DD HH:MM 01/01
98/02/06 16:02
98/02/07 09:21
98/02/17 15:44
