Connecting to the RS-232C Port at the Host
Note
Wiring for a Host Link Unit
(25-pin) Connection
1
5
Wiring for Other
Connections
When a connection is made to a personal computer at serial port A in the
memory link method, OMRON cable with connectors shown below are avail-
able.
Model Cable Length
CV500-CN228 2 m
XW2Z-S002 2 m
The cable's tensile load is 30 N. Do not subject it to loads greater than this.
Applicable Units: C200H-LK201-EV1
3G2A5-LK201-EV1
C500-LK203
3G2A6-LK201-EV1
CV500-LK201 (communications port 1)
Cables with connectors that can be used at serial port A:
XW2Z-200S (9-pin ⇔ 25-pin, 2 m)
XW2Z-500S (9-pin ⇔ 25-pin, 5 m)
CVM1/CV-series Host Link Units (CV500-LK201) have two types of connec-
tor; a 25-pin connector (communications port 1), and a 9-pin connector (com-
munications port 2). When using communications port 2, refer to Wiring for
Other Connections (Other Than the Memory Link Method) (page 75).
Serial Port A, B
NT631/NT631C
6
Pin
Abbreviation
number
Connector
FG
hood
1
2
SD
RD
3
RS-232C
RS
interface 4
CS 5
+5V
6
7
8
SG 9
(9-pin type)
9
* For Units that have a CTS setting selector switch, RS and CS do not have
to be shorted if this switch is set to 0 V.
Applicable Units:
CV500-LK201 (communications port 2)
CS1W-SCU21(-V1)
CJ1W-SCU21(-V1)
CPM1-10CDR-@
CPM1A-10CD@-@
CPM1A-30CD@-@
CPM2A-30CD@@-@
CPM2A-60CD@@-@
CPM2C-10@@@@@@-@
CQM1-CPU21-E
CQM1-CPU41-EV1
CQM1-CPU43-EV1
CQM1H-CPU11
CQM1H-CPU51
Connector Specification
9-pin ⇔ 25 pin
9-pin ⇔ 9 pin
PLC (host link unit)
Pin
Abbreviation
Shielding wire
number
1
FG
2
SD
3
RD
4 RS RS-232C
interface
5
CS
*
-
6
7
SG
8 -
-
-
-
-
- -
- ER
(25-pin type)
CJ1W-SCU41(-V1)
CPM1-20CDR-@
CPM1A-20CD@-@
CPM1A-40CD@-@
CPM2A-40CD@@-@
CPM2C-20@@@@@@-@
CQM1-CPU42-EV1
CQM1-CPU44-EV1
CQM1H-CPU21
CQM1H-CPU61
Section 4-1
1 14
13 25
