System Menu Operation Flow

6-1

System Menu Operation Flow

Create the Screen Data
Start Up the NT631/
NT631C (Display the
System Menu) (page 129)
Initialize the Memory
(page 135)
Transmit the Screen Data
(page 149)
Set the Memory Switches
(pages 152, 164, 184)
Start Operation (page 163)
System Maintenance
(page 187)
6-2

Starting the NT631/NT631C

6-2-1

Operation at Startup

Initial Processing
Follow the procedure below when using the NT631/NT631C for the first time
or changing the system program.
Create the data to be displayed on the NT631/NT631C by using the Support
Tool.
For details on creating screen data, refer to the NT-series Support Tool Ver.
4.@ for Windows Operation Manual (V061-E1-@).
Turn ON the power to the NT631/NT631C.
If no screen data has been registered, an error message is displayed. In this
case, press the OK touch switch on the error message screen to display the
System Menu.
If screen data has been registered and the RUN mode is established, perform
the appropriate operations on the touch panel to display the System Menu.
If necessary, initialize the memory of the NT631/NT631C by operation from
the System Menu.
Connect the Support Tool to the NT631/NT631C and transmit the screen data
from the Support Tool to the NT631/NT631C.
For details on connecting the Support Tool, refer to 3-2 Connecting to the
Support Tool (page 35).
Select the System Menu and set the operations of the NT631/NT631C — for
example the conditions for communications with the host — using the mem-
ory switches.
Connect the NT631/NT631C to the host and start operation.
If an error occurs during operation, check the I/Os, settings, etc., by referring
to this guide.
After checking that the hardware has been connected correctly, switch on the
power to the NT631/NT631C to start it up.
This section describes the operation of the NT631/NT631C when it is started
up.
The NT631/NT631C operates as follows when the power is switched ON, or
when it is reset.
Self diagnosis — including a check on the internal memory of the NT631/
NT631C and a system program check — and the internal processing required
for startup, are performed.
If an error occurs during initial processing, an error screen is displayed.
If there is an error in the system program, the system program must be re-
installed. For details on the installation procedure, refer to 6-5 Operations in
the System Installer Mode.
Section 6-1
129
