Rs-232C/Rs-422A Adapter; Related Parts And Equipment For Pt - Omron Programmable Terminals NT631 Setup Manual

Model List

RS-232C/RS-422A Adapter

Model
NT-AL001 RS-232C: 9-pin connector
RS-422A: 8-pin terminal block
RS-232C Adaptor, RS-422A Adaptor
Model
CPM1-CIF01 Links the RS-232C port of an NT631/NT631C and the peripheral port of a CPM1,
CPM2A, CPM2C, or SRM1 (compatible with host link, and NT Link (1:1))
CPM1-CIF11 Links the RS-422A port of an NT631/NT631C and the peripheral port of a CPM1,
CPM2A, CPM2C, SRM1 (compatible with host link)

Related Parts and Equipment for PT

Name
Support Tool* NT-ZJCAT1-EV4
Options NT631C-CFL01
NT631C-CFL02
NT610C-KBA04
NT625-KBA01
NT-MF261
3G2A9-BAT08
Reference: The Support Tool indicated above includes the system installer and the standard system programs
(Ver. 3.@/Ver. 4.@) for the NT31, NT31C, NT631, and NT631C. System programs for the earlier
NT30/620 PTs are also included.
Cables with Connectors for PT ↔ PLC/NT-AL001
Model Cable Length
XW2Z-200S 2 m
XW2Z-500S 5 m
XW2Z-200T 2 m
XW2Z-500T 5 m
XW2Z-S002 2 m
Note The following PLCs can supply +5 V: C200HX/HG/HE(-Z)E, CQM1H, CPM2A, CPM2C, CS1G/H/D, and
CJ1G/H/M.
Specification
Specification
Model
Applicable Units
Host Link Units with a 25-pin con-
nector
Host lInk Units with a 9-pin con-
nector
Personal computer with a 9-pin
connector
Remark
Compatible with PC/AT personal computers
For Windows 95/98/NT4.0/2000/XP (English version)
CD-ROM
Replaceable backlight (for NT631C-ST151@-EV1)
Replaceable backlight (for NT631C-ST141@-EV1)
Reflection suppressing protective sheet for NT631/NT631C
Chemical-resistant cover for NT631/NT631C
Memory Unit for NT631/NT631C
Spare battery
Communications Method
Serial port A host link
(RS-232C only)
Serial port A host link, NT link
(1:1) (RS-232C only)
Serial port A for using NT Sup-
port Tool
Appendix J
Specification
9-pin ↔ 25-pin
9-pin ↔ 9-pin
9-pin ↔ 9-pin
285
